Chapter 3

3.10 Print Button and Status Indicator Light

The Print Button and the Status Indicator Light are used to identify and perform many
functions. This section provides a description to familiarize you with the basic function of
the Print Button and the Status Indicator Light.
Figure 3-7
3.10.1

Print Button

Operation
Button Press
Button Pressed
and Held In
485TC Operator's Manual - 880058-0100
Status Light
Print Button and Status Indicator Light
A button press is used to generate a Test Ticket and to clear
errors.
Pressing and holding the button in will cause a line feed in certain
language modes.
Table 3-3 Print Button Description
Print
Button
Description
Getting Started
3-7
