Setting up the fixture

1:
2:
3:
4:
5:
Powering up
1:
2:

Adjusting the tilt

When pipe-mounting the fixture, tilt the fixture so that the base of the fixture
is perpendicular to the cyclorama.
1:
2:
3:
Adjusting the spill
control
Adjust the angle of the spill
control as needed.
ColorSource CYC v1.6
Plug power cord into the powerCON In connector on the rear of the
fixture.
Make any power-thru cable connections prior to applying a power
source.
Make any DMX connections, and if the fixture is the last in a DMX line,
terminate the fixture. See
Position the fixtures appropriately:
• Setback: Minimum recommended distance from the cyclorama is
2 ft (.61 m).
• Spacing: Position the fixtures arrayed with a 1.7-1 spacing for
optimal coverage, with a maximum spacing of 2-1. For example, if
fixtures are 2 ft (.61 m) from the cyclorama, position them a
maximum of 4 ft (1.22 m) apart from each other.
Plug power cord into power source.
Press any button to wake the display. The display shows the DMX
Setting the DMX address
address. See
Press the Mode button to access the Presets/Sequences menu. See
Setting presets and sequences
Loosen, but do not remove the yoke locking knobs.
Tilt the fixture so that the base of the fixture is perpendicular to the
cyclorama.
Tighten the yoke locking knobs.
Connectors
on
on
page 7
on
Spill
control
