Event Code Definitions

Table 15 contains a listing of event codes that may be reported by the
transceiver. The codes shown are a subset of a larger pool of codes used
for various GE MDS products. For this reason, the table does not show
a sequential listing of all code numbers. Only the codes applicable to
this product series are shown.
Event Event
Code Class Description
000 Major #0 Reserved
001 Major Hardware mismatch.
002 Major Frequency not programmed.
003 Major Authorization fault detected.
004 Major RF synthesizer out-of-lock condition.
005 Major #5 Reserved
006 Major A-to-D fault detected.
007 Major Voltage regulator fault detected.
008 Major Radio not calibrated. Factory calibration is required for proper
operation.
009 Major DSP download fault.
010 Major Flash write failure.
011 Major Checksum fault.
012 Major Receiver time-out. No data received within the specified
receiver time-out time.
013 Major Transmitter time-out.
014 Major Alarm Test.
015 Major VSWR fault. Possible antenna/feedline problem.
068 Major Excessive Ethernet traffic on interface.
016 Minor Unit address not programmed.
017 Minor Data parity error. This usually indicates a parity setting
mismatch between the radio and the RTU.
018 Minor Data framing error. May indicate a baud rate mismatch
between the radio and connected equipment.
019 Minor #19 Reserved.
020 Minor Configuration error.
021 Minor #21 Reserved.
022 Minor #22 Reserved.
023 Minor #23 Reserved.
024 Minor #24 Reserved.
025 Minor 6v regulator output not in valid range. If the voltage is too far
out of tolerance, operation may fail.
026 Minor DC input voltage approaching limit. If the voltage is too far out
of tolerance, operation may fail.
SD Series Technical Manual
Table 15. Event Codes
