Local Radio IP Port
The Local Radio IP Port setting is used to specify a port number for the
RJ-45 modular connector on the radio's front panel. Port numbers below
2000 should be avoided, as some are reserved for special applications in
data networks.
Local Radio IP Port
To set the port number, click in the box to the right of
and enter the desired port number.
Destination IP Address
This setting specifies the IP address associated with the device con-
nected through the RJ-45 modular connector on the radio's front panel
(typically a PC). Any valid IP address may be entered.
Destination IP Address
To set the address, click in the box to the right of
and enter the desired IP address.
Destination IP Port
The Destination IP Port setting is used to specify a port number for the
RJ-45 modular connector on the connected device (typically a PC). Port
numbers below 2000 should be avoided, as some are reserved for special
applications in data networks.
Destination IP Port
To set the destination port, click the box next to and
enter the desired port number.
TCP Keepalive Time
This setting specifies the number of seconds that the TCP socket is
active after the receipt of data.
TCP Kee-
To set the TCP Keepalive time, click in the box to the right of
palive
and enter the desired time in seconds.
Restoring Configuration
In some cases, you may wish to revert to the previous configuration of
the screen, prior to any changes being committed. This might be useful
if one or more settings were inadvertently changed and you wish to
return to a "known state." To restore the prior settings, simply click
Restore Configuration
.
Committing Configuration Settings
Once you are satisfied with all of the settings on the screen, you make
Commit Configuration Changes com-
them active by clicking . The message
mitted
appears at the bottom of the screen to confirm the action.
