GE MDS SD4A Technical Manual page 104

96
FCC ID:
IC ID:
FCC Emission Designators (SD4):
6.25kHz B/W (MODEM 4800F):
12.5 kHz B/W (MODEM 9600,
9600M, 4800):
25.0 kHz B/W (MODEM 19200):
DATA CHARACTERISTICS
Signaling Types:
COM2 Data Rates:
Data Latency:
PRIMARY POWER
Voltage:
NOTE: Early SD4 models supported 10.5 to 16 Vdc power, not 10 to 30 Vdc. Check the
labeling above the power connector to confirm the operating range for your unit.
TX Supply Current (Typical):
RX Supply Current (Typical):
Fuse:
ENVIRONMENTAL
Humidity:
Temperature Range:
Duty Cycle:
SD Series Technical Manual
SD4: E5MDS-SD4
SD4: 101D-SD4
6K00F1D, F2D, F3D
11K2F1D, F2D, F3D
20K0F1D, F2D, F3D
RS-232/485; DB-9 Female connector
Ethernet 10/100 Mbps; RJ-45F connector
300–115200 bps, asynchronous
11 ms typical (transparent)
10.0 to 30 Vdc (Negative ground only)
2.5 Amperes maximum @ 5 Watts RF Output
Operational—125 mA, Nominal
Sleep—<10 mA typical @ 13.8 Vdc
5-Ampere, internal
95%, non-condensing
–40 to 70 degrees C (–40°F to 158°F)
50% (ambient temperature, -40C to +70C)
Continuous (internal temperature <= +80C)
MDS 05-4846A01, Rev. F
