Table 11. Common Tasks with Device Manager (Continued)
Task
If you wish to...
Category
View logged Events
Set alarm signal output (active high/low)
Issue Alarm Test
View I/O Statistics for COM1, COM2, Ethernet
Port, Remote Programming, Ethernet Interface,
Data Link Layer, and MAC
The remainder of this section covers the screens for Configuration,
Maintenance, and Status of the transceiver. The emphasis is on available
selections, how to access them, and their effect on radio operation. If
you are unsure of the setting required for a particular radio in your net-
work, consult your Network Administrator for assistance.
NOTE: The Device Manager screens shown in this manual were
obtained from a radio operating in a lab environment and are
provided as examples only. The parameters and settings shown
may differ from those seen in field service conditions.
SD Series Technical Manual
Refer to this Screen
Maintenance & Status>>
Event Log, Page 69
Maintenance & Status>>
Alarm Summary>>
Alarm Signal Configuration,
Page 70
Maintenance & Status>>
Radio Test>>
Alarm Test, Page 76
Maintenance & Status>>
Performance>>
I/O Statistics, Page 72, and
Ethernet Statistics, Page 72
MDS 05-4846A01, Rev. F
