12
HOST
COMPUTER
Figure 6. Typical Point-to-Point Link

IP/Ethernet Polling and Terminal Server Operation

Modern data/control networks often employ IP/Ethernet connectivity
throughout the system. The SD transceiver is well suited to provide con-
nectivity between such sites using its RJ-45 modular connector on the
front panel and enabling Ethernet Bridging capabilities. Figure 7 shows
an overview of such a system.
Note that the Remote radio on the right side of the illustration uses a
serial connection. The SD radio's Terminal Server feature allows direct
IP/addressing of serial ports on selected radios. See "Terminal Server
COM1/2 Configuration" on Page 58 for more details.
REMOTE RADIO
(One of several possible sites)
Ethernet
Ethernet RTU
Figure 7. IP/Ethernet Polling Example
SD Series Technical Manual
Invisible place holder
REMOTE RADIO
MASTER RADIO
RTU
Invisible place holder
MASTER UNIT
To Ethernet Port
Ethernet
REMOTE RADIO
(One of several possible sites)
Serial
Serial RTU
(Terminal Server Connection)
MDS 05-4846A01, Rev. F
