GE MDS SD4A Technical Manual page 46

38
Table 11. Common Tasks with Device Manager (Continued)
Task
If you wish to...
Category
View Serial No., Model 1 (hardware), Model 2
(software) version, Firmware Version, Build
Date
Set Owner Name/Message, enable/disable
Sleep Mode, set COM LED mode, Radio Mode
Configure time delays to identify packets on
serial ports
Configure Media Access Control (MAC) settings
Configure Store and Forward (SAF)
Configure Virtual LAN (VLAN)
Configure Terminal Server 1/2
Configure Unit ID and/or DLINK diagnostics
settings
Set Password for radio
Set Device Security (enable/disable local login
requirement, enable/disable Telnet access)
Set Wireless Security parameters (Encryption
on/off, phrase, DLINK Security on/off)
Configure the IP settings (Static IP Address,
Static IP Netmask, Static Default Gateway,
DHCP enable/disable, Virtual Radio
Channels–VRCs)
Configure Ethernet Bridging
Configure the Ethernet Port settings
(Enable/disable port, set mode, Local IP Port,
Destination IP Address, Destination IP Port,
TCP Keepalive time)
SD Series Technical Manual
Refer to this Screen
Overview>>
SD Summary, Page 35
Configuration>>
Radio>>Device Settings,
Page 43
Configuration>>
Radio>>
Packet Settings, Page 44
Configuration>>
Radio>>
Media Access Control>>
Settings, Page 44
Configuration>>Radio>>
Media Access
Control>>Page 44
Configuration>>Features>>
VLAN Config., Page 50
Term Srvr COM1 Config.,
Page 58
Configuration>>
Radio>>
Diagnostic Settings,
Page 47
Configuration>>
Security>>
Login Password, Page 67
Configuration>>
Security>>
Device Security, Page 66
Configuration>>
Security>>
Wireless Security, Page 67
Configuration>>
Communication Ports>>
IP Configuration, Page 65
Configuration>>
Features>>
Bridge Configuration,
Page 50
Configuration>>
Communication Ports>>
IP Configuration, Page 65
MDS 05-4846A01, Rev. F
