Ip Stream Configuration - ZeeVee ZyPerMX User Manual

5. Locate the Addr Type field:
► If this field is set to DHCP, then all network parameters are assigned
automatically, providing there is a DHCP server connected to the network.
► If the Addr Type is set to Static, then follow steps 6 - 9.
6. Enter the IP address in the IP Address field. When a value is changed, within a field, a green
check mark will appear next to the field.
7. Enter the subnet mask in the Mask field.
8. Enter the gateway address in the Gateway field.
9. Click the Apply button to commit the changes. To discard recent changes, click the Reset
button.
Basic Operation
6

IP Stream Configuration

The ZyPerMX can be configured to output either unicast or multicast IP streams using UDP or
RTP protocols.
1. Login to the Maestro web interface. See
2. Click the IP Channel Plan tab.
3. To enable IP streaming, be sure that the Enabled drop-down box is set to Enable. This is
the default setting. To disable IP streaming, select Disable from the drop-down list.
Basic Operation
Logging In (page 4) for more information.
7
