Appendix

Specifications

Video Input
1 x HDMI Type A, 19-pin, female
Input Signal
0.5 ~ 1.2 Vp-p
Input DDC Signal
5 Vp-p (TTL)
Video Output
1 x LAN (PoE), 10/100/1000Base-T
Output Type
H.264/MPEG-4 AVC
Video Encoding Bit Rate
2 Mbps ~ 30 Mbps (configurable)
Input / Output Resolutions
60 Hz
640 x 480
800 x 600
1024 x 768
1280 x 768
1280 x 800
1280 x 1024
1360 x 768
1366 x 768
50 Hz
720 x 576p
1280 x 720p
30 Hz
1280 x 720p
25 Hz
1920 x 1080p
24 Hz
1920 x 1080p
Audio Input
1 x HDMI Type A, 19-pin, female
Audio Sampling Rate
48 kHz
Audio Compression
Linear PCM (fixed 1.6 Mbps)
and Sampling Rates
AAC (configurable, 32 k, 48 k, 64 k, 96 k, 128 k, 192 k,
240 k
Operating Temperature
+32 ºF to +113 ºF (0 ºC to +45 ºC)
Operating Humidity
10% to 90% (non-condensing)
Storage Temperature
-4 ºF to +140 ºF (-20 ºC to +70 ºC)
Storage Humidity
10% to 90% (non-condensing)
Appendix
1440 x 900
1400 x 1050
1600 x 1200
1680 x 1050
1920 x 1200
720 x 480p
1280 x 720p
1920 x 1080p
1920 x 1080p
1920 x 1080p
25
