Safety Instructions

INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS
Important Safety Instructions. Save These Instructions.
WARNING: When using electronic products, basic precautions should always be followed,
including:
1. Keep these instructions.
2. Heed all warnings.
3. Follow all instructions.
4. Do not use this apparatus near water.
5. Clean only with a dry cloth.
6. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
7. Do not install or place this product near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
8. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for replacement of the obsolete outlet.
9. Power cord must be accessible to allow for the removal of the power from the unit.
10. Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Unplug this apparatus during lightning storms or when unused for long periods of time.
12. Only use attachments/accessories specified by the manufacturer.
13. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally,
or has been dropped.
14. WARNING: To reduce the risk of fire or electric shock do not place this apparatus in a position
where it is exposed to dripping or splashing liquids, rain, moisture, or excessively high humidity.
Objects containing liquid shall not be placed in proximity to the unit such that they present a risk of
spillage onto the apparatus.

FCC Statement

FCC Compliance and Advisory Statement: This hardware device complies with Part 15 of the FCC
rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interfer-
ence, and 2) this device must accept any interference received including interference that may cause
undesired operation. This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a commercial installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed or used in accordance with the instruc-
tions, may cause harmful interference to radio communications. However there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures: 1) reorient or
relocate the receiving antenna; 2) increase the separation between the equipment and the receiver; 3)
connect the equipment to an outlet on a circuit different from that to which the receiver is connected; 4)
consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not ex-
pressly approved by the party responsible for compliance could void the user's authority to operate the
equipment. Where shielded interface cables have been provided with the product or specified additional
components or accessories elsewhere defined to be used with the installation of the product, they must
be used in order to ensure compliance with FCC regulations.
ii
Features and Package Contents
Features
● Input: One standard HDMI 1.3 input
○ Resolutions from common Standard Definition, through all resolutions including 1080p60, up
to and including1920x1200 @ 60Hz.
● Standards-based H.264/MPEG-4 AVC video compression.
○ High-profile H.264/MPEG-4 AVC compression standard in real-time.
○ Adjustable video bandwidth targets from 2 Mbps through 20 Mbps.
○ Assignable Program Number and Short Channel Name inserted in encoded stream.
○ Output resolution can track input resolution, or be fixed at a static size.
● Audio input as component of HDMI input.
○ LPCM, AAC, MPEG1 Layer 2 inputs formats all supported.
○ Fixed programmable data rate LPCM supported.
○ Variable AAC audio compression supported.
● Output: one standard 10/100/1000Base-T Ethernet port.
○ Common communications protocols/methods supported to includeTCP/IP, ARP, DHCP, ICMP
(ping), IGMP, HTTP, RTP, RTSP, and UDP.
● Output stream can be set to UDP or RTP using either unicast or multicast addressing.
● RTP / RTSP supported at up to four simultaneous sessions.
● UDP video stream can be decoded by any number of Ethernet attached output devices.
○ PC / Mac, VLC, IP Set Top Box, IPSTB-enabled television, or custom appliance.
● Maestro Web GUI browser management of unit.
● Custom, downloadable idle screen for active display when no input is present.
● Bonjour protocol supported for automatic discovery of ZyPerMX on network.
● Power-over-Ethernet (PoE) supported allowing for ZyPerMX to be powered by an appropriately
capable switch or power injector.
● Software upgradable through the Maestro web management application.
● Rack-mountable 1U, half rack width metal enclosure input/output resolutions up to 1080p and
1920 x 1200 @ 60 Hz
What's In The Box
Here's what you can expect to find when you open the package:
1 x ZyPerMX
1 x Power Adapter
2 x Mounting Ears
