ZeeVee ZyPerMX User Manual page 7

4. Enter the destination IP address in the Dest. IP Address field. If you enter a valid IP
multicast address (range 224.0.0.0 to 239.255.255.255), any endpoint registered with that
multicast receives the stream. If you enter a valid IP unicast address, only that specific ad-
dress receives the IP stream.
5. Enter the port number in the Dest. IP Port field. The arrows can also be used to set the port
number. The supported port range is 1025 to 65534.
The destination IP port must not conflict with other IP protocols. If necessary,
contact the System Administrator for assistance.
6. Enter the desired program number from 1 to 65535 in the Program Number field.
The spinner controls may also be used to set the program number.
Select either UDP or RTP for the stream type from the TS Type drop-down list.
7.
TS Type Description
UDP Uses less overhead; lacks packet acknowledgement or error
correction.
RTP Protocol built on top of UDP; delivers real-time multimedia and
detects out of sequence packets.
Basic Operation
8
8. Enter a description of the content in the Short Name field. Often, the viewing client will
display the short channel name when tuning to different streams. The short name cannot
exceed 60 characters in length. Letters, numbers, and spaces are permitted.
9. Enter a description of the content in the Long Name field. The long name cannot exceed 60
characters in length. Letters, numbers, and spaces are permitted.
10. Click the Output Resolution drop-down list to select the desired output resolution.
The following resolutions are supported:
Note that if Auto is selected, the resolution of the encoded output stream will match the
resolution of the input video stream.
11. Click the Apply button to save the changes or click the Reset button to discard any
changes.
Basic Operation
9
