Command-Centre
5.1 External bypass valve
The diverter bypass valve allows the user to choose to have the boiling feed water bypass the internal
filter and only be filtered by the external filtration. This diverter valve is located at the rear panel of the
Command-Centre
, see the diagram below.
TM
Check the table below to determine which filter bypass position you need for your product.
If no external filter is installed, select position A
A
2
Leave in position A until after commissioning (section 6). Select position B if a scale filter is fitted, before
flushing the scale filter as described on page 22.
5.2 Braided hose fitting
Install the mains water braided hoses to the Command-Centre
Page 18 of 28
Section 5
1
4
Rotate 90°
only
3
802149UK Celsius residential - Installation instructions -Jan 2016 v2.03
installation
TM
If an external filter is installed, select position B
Rotate 90°
only
2
before locating in place.
TM
B
1
4
3
