Summary of Contents for Zip ChillTap Extra CT2/140
- Page 1 Installation and operating instructions Zip ChillTap Extra ® Filtered Ambient and Chilled drinking water appliances for work and home ChillTap Extra ® Affix model number label here Page 1 of 12 Zip CT2/140, DOMCT1- Installation & operating instructions - June 2015 v1.01...
-
Page 2: Table Of Contents
Repairs must only be carried out by Zip Heaters (UK) Ltd or an authorised Zip service engineer. If the power supply cable is damaged it must be replaced by a Zip service engineer or a qualified electrician. -
Page 3: Technical Data
The products are listed under the WRAS (Water Regulations Advisory Scheme) Water Fittings and Materials Directory. Zip Heaters (UK) Ltd cannot be held liable for any damages caused by failure to observe these instructions. Caution: Refrigerant The chiller units contain R134a refrigerant under pressure. No part of the unit should be exposed to a naked flame. -
Page 4: General Installation Instructions
(See Spare parts and accessories page 3). Electrical Electrical connection must be made by a Zip service engineer or a qualified electrician. (See Safety information, page 2). This appliance must be earthed. -
Page 5: Chilltap ® Extra Ct2/140 And Domct1 Installation Instructions
Allow an envelope of at least 50mm around the chiller unit to permit free airflow. Both the top and the front of the chiller must remain accessible for servicing purposes. Electrical connection Electrical connection must be made by a Zip service engineer or a qualified electrician. (See Safety information page 2). Connect to water supply Install the isolation valve (not supplied) in the mains cold water supply line in the under-counter cupboard space. -
Page 6: Chilltap ® Extra Ct2/140 And Domct1 Configuration Diagram
Cut pipes should not be overly long, but must allow sufficient length to avoid stress at connection points. Page 6 of 12 Zip CT2/140, DOMCT1- Installation & operating instructions - June 2015 v1.01... -
Page 7: Commissioning
When finished dispensing water, both levers automatically return to the OFF (vertical) position once finger pressure has been removed. Page 7 of 12 Zip CT2/140, DOMCT1- Installation & operating instructions - June 2015 v1.01... -
Page 8: Filter Replacement
Not changing the filter cartridges when required may cause the water to become biologically unsafe. Pull Use only a Zip filter to match the one used in your system product (see Spare parts Rotate and accessories page 3). The filter cartridge can be obtained through plumbing suppliers or direct from Zip. -
Page 9: Cleaning And Service
Before calling for service, check that both the water and electricity supplies are turned on and functional. Call Zip, a qualified electrician or plumber for assistance, service, spare parts, or enquiries. Zip customer service 0845 6 005 005, 0345 6 005 005. -
Page 10: Warranty Information And End Of Life Disposal
Furthermore, this warranty does not displace any statutory warranty, but, to the extent to which Zip is entitled to do so, the liability of Zip under any statutory warranty will be limited at Zip’s option to the replacement of the appliance or supply of equivalent... - Page 11 Notes Page 11 of 12 Zip CT2/140, DOMCT1- Installation & operating instructions - June 2015 v1.01...
-
Page 12: Contact Details
Web: www.zipheaters.co.uk e-mail: info@zipheaters.co.uk Registering Your Purchase Registering your Zip installation on the Zip website may help to establish date of installation should it become necessary to service the appliance under terms of the Zip warranty. Page 12 of 12...
