 Reset Configuration Data
Normally, you leave this item Disabled. Select Enabled to reset Extended System
Configuration Data (ESCD) when you exit Setup or if installing a new add-on cause the system
reconfiguration a serious conflict that the operating system can not boot. Options: Enabled,
Disabled.
 Resources Controlled By
The Award Plug and Play BIOS can automatically configure all boot and Plug and
Play-compatible devices. If you select Auto, all interrupt request (IRQ), DMA assignment, and
Used DMA fields disappear, as the BIOS automatically assigns them. The default value is
"Manual".
 PCI/VGA Palette Snoop
Some non-standard VGA display cards may not show colors properly. This item allows you to
set whether MPEG ISA/VESA VGA Cards can work with PCI/VGA or not. When enabled, a
PCI/VGA can work with a MPEG ISA/VESA VGA card; when disabled, a PCI/VGA cannot work
with a MPEG ISA/VESA Card.
 Rapid Card Boot First
This item helps you use additional PCI RAID card boot.
 Maximum Payload Size
When using DDR SDRAM and Buffer size selection, another consideration in designing a
payload memory is the size of the buffer for data storage. Maximum Payload Size defines the
maximum TLP (Transaction Layer Packet) data payload size for the device.
