SHB100 LGA775 SBC User's Manual
3.4.2
How to install the PICMG1.3 backplane for SHB100
The SHB100 only defined one x16 PCI Express link on the connectors A/B(This x16
PCIe link is designed to support PCI Express video/graphics cards on an SHB
Express™).
If the customer want to use the SHB100 for other brand name of PICMG1.3 backplane.
Please double check the backplane could supportPCI-Expressx4orPCI-Expressx1
(SHB100 only support one PCI-Expressx4 and four PCI-Expressx1)
Hardware Installation
25
