SHB100 LGA775 SBC User's Manual
2.4.6

Serial Port Interface Connectors (CN3, CN6)

The serial interface for the board consists of COM1 port (CN3) and COM2 (CN6)
supports RS-232/RS-422/RS-485.
Pin Signal
1 Data Carrier Detect (DCD)
3 Receive Data (RXD)
5 Transmit Data (TXD)
7 Data Terminal Ready (DTR)
9 Ground (GND)
COM2 Serial Port 10-pin (Box-header) Connector Pin Assignment list
Pin
1
2 No connector
3
4 No connector
5
6 No connector
7
8 No connector
9
10
2.4.7 Internal Mouse/Keyboard Connector (CN20/CN21)
The board provides a keyboard (CN21) and Mouse (CN20) interface with two 5-pin
connectors.
16
Pin
2
4
6
8
10
Signal
RS-422 RS-485
TX- DATA-
No connector
TX+ DATA+
No connector
RX+ No connector
No connector
RX- No connector
No connector
GND GND
GND GND
Clock 1
Data 2
No Connection 3
GND 4
Power
5
Signal
Data Set Ready (DSR)
Request to Send (RTS)
Clear to Send (CTS)
Ring Indicator (RI)
NC
Board and Pin Assignments
