SHB100 LGA775 SBC User's Manual
2.3.9

CMOS Clear Jumper (JP14)

Description
CMOS Clear
2.3.10 Processor List for Intel Core2 Duo CPU(For B1 PCB
version of SHB100 only)
Proc No Clock Speed
E6700 2.6
E6600 2.44
E6400 2.133
E6300 1.866
E4300 1.8
10
Function Jumper Setting
Normal
(Default)
Clear
CMOS
Cache FSB
4M 1066
4M 1066
2M 1066
2M 1066
2M 800
3 2 1
3 2 1
Processor
Socket
Generation
LGA775 Conroe
LGA775 Conroe
LGA775 Conroe
LGA775 Conroe
LGA775 Conroe
Board and Pin Assignments
Note
Embedded
Embedded
