2. ADVANCED OPERATIONS
About the 5 MHz frequency band operation (USA version only)
Operation on the 5 MHz frequency band is allowed
on 5 discrete frequencies and you must adhere to the
following:
• The USB, USB Data, PSK, and CW modes.
• Maximum of 100 watts ERP (Effective Radiated
Power)
• Maximum 2.8 kHz bandwidth
It is your responsibility to set all controls so that
transmission in this frequency band meets the
stringent conditions under which amateur operations
may use these frequencies.
TIP: We recommend that you save these
frequencies, modes and ilter settings into memory
channels, for easy recall.
NOTE: To assist you in operating within the rules speciied
by the FCC, transmission is illegal on any frequencies
other than the ive shown in the tables below.
For the USB and USB data modes:
The FCC speciies center frequencies on the 5 MHz
frequency band. However, the transceiver displays
carrier frequency. Therefore, tune the transceiver
to 1.5 kHz below the speciied FCC channel center
frequency.
Transceiver displayed
frequency
5.33050 MHz
5.34650 MHz
5.35700 MHz
5.37150 MHz
5.40350 MHz
For the CW and PSK modes:
The transceiver displays the center frequency.
Therefore, tune the transceiver to the speciied FCC
channel frequency when you operate in these modes.
Transceiver displayed
frequency
5.33200 MHz
5.34800 MHz
5.35850 MHz
5.37300 MHz
5.40500 MHz
37
FCC channel center
frequency
5.33200 MHz
5.34800 MHz
5.35850 MHz
5.37300 MHz
5.40500 MHz
FCC channel center
frequency
5.33200 MHz
5.34800 MHz
5.35850 MHz
5.37300 MHz
5.40500 MHz
