Keysight 3000 X-Series Oscilloscopes Performance Test Record
Serial No. ______________________________________
Test Interval ____________________________________
Recommended Next Testing ________________________
Threshold Specification
Accuracy Test 5 V - 250 mV
(100 mV + 3% of 5 V + 250 mV
threshold setting)
-5 V - 250 mV
-5 V + 250 mV
0 V - 100 mV
0 V + 100 mV
DC Vertical Gain Accuracy
Range Power Supply Setting
5 V/Div 35 V
2 V/Div 14 V
1 V/Div 7 V
500 mV/Div 3.5 V
200 mV/Div 1.4 V
100 mV/Div 700 mV
50 mV/Div 350 mV
20 mV/Div 140 mV
10 mV/Div 70 mV
5 mV/Div 35 mV
2 mV/Div 14 mV
1 mV/Div 7 mV
2000/3000 X-Series Oscilloscopes Service Guide
Limits
4.750 V
5.250 V
-5.250 V
-4.750 V
-100 mV
100 mV
Test Limits
34.2 V to 35.8 V
13.68 V to 14.32 V
6.84 V to 7.16 V
3.42 V to 3.58 V
1.368 V to 1.432 V
684 mV to 716 mV
342 mV to 358 mV
136.8 mV to 143.2 mV
68.4 mV to 71.6 mV
34.2 mV to 35.8 mV
13.36 mV to 14.64 mV
6.36 mV to 7.64 mV
Testing Performance
Test by _____________________________
Work Order No. ______________________
Temperature ____________
Ch D7-D0 Ch D15-D8
________ ________
________ ________
________ ________
________ ________
________ ________
________ ________
Channel 1 Channel 2 Channel 3* Channel 4*
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
Continued on next page.
2
________
________
________
________
________
________
________
________
________
________
________
________
