Keysight Technologies InfiniiVision 2000 Service Manual page 30

2
Testing Performance
Table 8
Vol ts/Div Setting
5 V/Div
2 V/Div
1 V/Div
500 mV/Div
200 mV/Div
100 mV/Div
50 mV/Div
20 mV/Div
10 mV/Div
5 mV/Div
2 mV/Div
1 mV/Div
1
Reduce Noise"
2
is defined as 8 divisions times the V/div setting.
30
Settings Used to Verify DC Vertical Gain Accuracy, 2000 X-Series Models
Precision Source Setting
35 V
14 V
7 V
3.5 V
1.4 V
700 mV
350 mV
140 mV
70 mV
1
35 mV
1, 2
14 mV
1, 2
7 mV
A blocking capacitor is required at this range to reduce noise. See
on page 34.
Full scale is defined as 32 mV on the 2 mV/div and the 1 mV/div range. Full scale on all other ranges
Test Limits
33.8 V
13.52 V
6.76 V
3.38 V
1.352 V
676 mV
338 mV
135.2 mV
67.6 mV
33.4 mV
12.72 mV
5.72 mV
"Use a Blocking Capacitor to
2000/3000 X-Series Oscilloscopes Service Guide
to 36.2 V
to 14.48 V
to 7.24 V
to 3.62 V
to 1.448 V
to 724 mV
to 362 mV
to 144.8 mV
to 72.4 mV
to 36.6 mV
to 15.28 mV
to 8.28 mV
