2 Testing Performance

Overview / 18
List of Test Equipment / 19
To construct the test connector (for use with MSO models only) / 21
To test digital channels (MSO models only) / 23
To verify digital channel threshold accuracy (MSO models only) / 24
To verify DC vertical gain accuracy / 28
To verify dual cursor accuracy / 35
To verify band width (-3 dB) / 40
To verify time base accuracy / 45
To verify trigger sensitivity / 47
Keysight 2000 X-Series Oscilloscopes Performance Test Record / 53
Keysight 3000 X-Series Oscilloscopes Performance Test Record / 55
This chapter explains how to verify correct oscilloscope operation and perform
tests to ensure that the oscilloscope meets the performance specifications.
17
