2
Testing Performance
Table 1 List of test equipment (continued)
Equipment
Shorting cap
Blocking capacitor
50 Ohm Feedthrough
Termination
* Required only for testing digital channels of oscilloscopes that have the MSO option.
Most parts and equipment are available at www.keysight.com. See respective manufacturer's websites for their equipment.
†
These parts available at www.parts.keysight.com at the time this manual was published.

Conventions

The following conventions will be used when referring to oscilloscope models
throughout this chapter.
Table 2
Models
MSO-X /DSO-X 2002A, MSO-X /DSO-X 2004A
MSO-X /DSO-X 2012A, MSO-X /DSO-X 2014A
MSO-X /DSO-X 3012A, MSO-X /DSO-X 3014A
MSO-X /DSO-X 2022A, MSO-X /DSO-X 2024A
MSO-X /DSO-X 3024A
MSO-X /DSO-X 3032A, MSO-X /DSO-X 3034A
MSO-X /DSO-X 3052A, MSO-X /DSO-X 3054A
MSO-X /DSO-X 3102A, MSO-X /DSO-X 3104A
20
Critical Specifications
BNC
Note: if a BNC blocking capacitor is not available use
an SMA blocking capacitor.
Ω
50 BNC (f) to BNC (m)
Conventions
Recommended Model/ Part Number
Keysight 1250-0774
Keysight 11742A +
Pomona 4289 +
Pomona 5088
Keysight 0960-0301
Referred to as:
70 MHz Models
100 MHz Models
200 MHz Models
350 MHz Models
500 MHz Models
1 GHz Models
2000/3000 X-Series Oscilloscopes Service Guide
