Keysight Technologies InfiniiVision 2000 Service Manual page 54

2
Testing Performance
Dual Cursor Accuracy
Range Power Supply Setting
5 V/Div 35 V
2 V/Div 14 V
1 V/Div 7 V
500 mV/Div 3.5 V
200 mV/Div 1.4 V
100 mV/Div 700 mV
50 mV/Div 350 mV
20 mV/Div 140 mV
10 mV/Div 70 mV
5 mV/Div 35 mV
2 mV/Div 14 mV
1 mV/Div 7 mV
Band wid th (-3 dB) Model
202x
201x
200x
Time Base Accuracy Limits
Time Base Accuracy Limit: ±25 ppm ±5 ppm per year
(aging)
Internal Trigger Sensitivity
Generator Setting
200 MHz models: 200 MHz
100 MHz models: 100 MHz
70 MHz models: 70 MHz
External Trigger Sensitivity
Generator Setting
200 MHz
100 MHz
* Where applicable
54
Test Limits
33.6 V to 36.4 V
13.44 V to 14.56 V
6.72 V to 7.28 V
3.36 V to 3.64 V
1.344 V to 1.456 V
672 mV to 728 mV
336 mV to 364 mV
134.4 mV to 145.6 mV
67.2 mV to 72.8 mV
33.2 mV to 36.8 mV
12.56 mV to 15.44 mV
5.56 mV to 8.44 mV
Test Limits
-3 dB at 200 MHz
-3 dB at 100 MHz
-3 dB at 70 MHz
Test Limits
< 10 mV/div: greater of 1 div
or 5 mVpp
>= 10 mV/div: 0.6 div
Test Limits
350 mV
200 mV
2000/3000 X-Series Oscilloscopes Service Guide
Channel 1 Channel 2 Channel 3* Channel 4*
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
________ ________ ________
Channel 1 Channel 2 Channel 3* Channel 4*
________ ________ ________
________ ________ ________
________ ________ ________
Calculated Measured Pass/Fail
time base time base
accuracy error (ppm)
limit (ppm)
_________ ________ ________
Channel 1 Channel 2 Channel 3* Channel 4*
________ ________ ________
________ ________ ________
Ext Trig In
________
________
________
________
________
________
________
________
________
________
________
________
________
________
________
________
________
_______
_______
