Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide
Field
Base Station - Synchronization
Type
Auto radio sync (deployment only)
(Optional)
Primary radio sync (RPN)
(Optional)
Secondary radio sync (RPN)
(Optional)
Base Station - RSSI map (Only visible if more than one base station on the system)
RPN/RSSI dB/Offset

Administration - Clusters - Cluster 0

Field
Cluster - General
Name
14215700-IG, Edition 7.0
January 2018, Original document
This setting controls the synchronization type used for the
specific base station/DECT radio.
Possible values: Free running, Radio, LAN or Radio/LAN
Gateway.
Select Free running, if you want to configure this base sta-
tion as sync master. Otherwise select either Radio, LAN or
Radio/LAN Gateway, depending on the synchronization
method.
Default value: Radio
Note: System wide settings for synchronization are located
under Configuration > Wireless Server > Base stations.
For more information, see Synchronization and Deployment
Guide.
If enabled, the base station will be auto synchronized while
deploying the system.
Note: This must only be used while deploying the system.
RPN identifying the base station used for primary radio syn-
chronization.
RPN identifying the base station used for secondary radio
synchronization.
Possible to see the RSSI values of the base stations the
selected base station is synchronizing on (Primary syn-
c/Secondary (Alternative) sync).
For more information about RSSI values, see Syn-
chronization and Deployment Guide.
Enter a name for the cluster.
E.g. Site A, Site B, Site C.
215
