Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide
Field
Update media resource firmware - Automatic
Enable (Optional)
Force (Optional)
Start time (Optional)
Update media resource firmware - Manual
Firmware file (Optional)
Start media resource No
End media resource No
14215700-IG, Edition 7.0
January 2018, Original document
Setting
Default value: Disabled
Enable this, if you want to make automatic update possible. The
media resources will be automatically updated using the default
firmware. Also new media resources automatically update to
new default firmware when connected.
Note: If the default firmware version changes, the update pro-
cess will start automatically according to the chosen values in
the Force and Start time fields.
Note: Using provisioning for base stations, media resources
and handsets, enabling automatic update is required. This can
be done either through the XML configuration file or the web
based Administration Page. For more information, see Pro-
visioning Guide.
When Force is enabled, the media resources will be updated at
the selected Start time.
If Force is disabled, the media resources will be updated when
they become idle after the selected Start time.
Default value: Immediately
If you want to upload later, select an appropriate time within the
next 24 hours.
Click Save.
The firmware file can be either a previously uploaded default
firmware file, or a new firmware file chosen. A new firmware file
has to be a valid firmware file with the extension .bin.
Select either Default or Upload.
The index number of the first media resource to be updated.
You can check media resource numbers under Admin-
istration > Media resource.
The index number of the last media resource to be updated.
130
