SpectraLink IP-DECT Server 400 Installation And Configuration Manual page 157

Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide
Field
Import
Encoding
Number fields
Phonebook Configuration - LDAP
LDAP
URI
Blind user (Optional)
Blind password (Optional)
Base (Optional)
Filter (Optional)
Attributes
14215700-IG, Edition 7.0
January 2018, Original document
Setting
Browse for the CSV file to import.
Note: The CSV file must contain correct format. For
more information, see"Example of CSV File Format" on
page 159.
Select the correct encoding for the CSV file. You can
choose between UTF-8, ISO/IEC 8859-1 or Window-
1252.
Note: The encoding depends on the software that was
used to generate the CSV file. If you use Microsoft Win-
dows, you will probably select Windows-1252.
Enter the indexes of the columns containing dialable num-
bers.
Enable this if you want to configure the server to retrieve
phone book data using LDAP server.
For an example of LDAP configuation, see
LDAP Configuration" on the next
Enter the URI of the LDAP server.
E.g. ldap://example.com
Enter the username used for authentication against
LDAP.
Note: It might be necessary to specify the path for user-
name (DOMAIN\username).
E.g. CN=Manager, DC=example, DC=com.
Enter the Bind user's password.
Enter the base path where the users are located in the
LDAP structure.
E.g. DC=example, DC=com.
Enter the filter used for the LDAP query. The
(objectClass=person) filter can be used successfully in
most cases.
Enter the LDAP attributes you want to query the LDAP
for, separated by a comma.
E.g. displayName,telephoneNumber, mobile.
"Example of
page.
157
