Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide
The DECT radius of coverage is up to 600 meters/2000 feet with a handset in free sight.

Description - Spectralink DECT Repeater

The Spectralink DECT Repeater is a building block to be used to extend the coverage area in a wire-
less Spectralink DECT solution. The repeater does not increase the number of traffic channels, how-
ever it provides a larger physical spreading of the traffic channels and thereby increases the
coverage area established with the Spectralink IP-DECT Base Stations.
The repeaters are mainly used in areas with limited traffic. The Spectralink DECT Repeater is avail-
able with either 2 or 4 voice channels. It is wireless and does not need physical connection to the
Spectralink IP-DECT Server, making it very easy to install. The repeaters can be supplied with an
external antenna making it possible to create radio coverage in a remote area without cabling to the
rest of the installation.
The base station can support up to 3 repeaters.

System Capacity Overview

Below you will find an overview of the system capacity of the Spectralink IP-DECT Server:

System Capacity - Servers

Description
IP-DECT Servers
Media Resources
IP-DECT Base Stations
Protocol supported
Max number of simultaneous SIP
calls via license
Simultaneous calls
Codecs supported
14215700-IG, Edition 7.0
January 2018, Original document
IP-DECT Server 400
1
-
-
SIP
12
-
G.711a, G.711u
IP-DECT Server 6500
1
32
1024
SIP
1024
11 Radio Base Stations
32 Media Resources
G.711a, G.711u, G.729
20
