Cautions

Avoid abrupt changes of the ambient temperature.
In case of problems or questions which may arise when you use the CTVideo, please contact our service
department.

Model Overview

The sensors of the CTVideo series are available in the following basic versions:
Model Model code
CTVM-1 1L/ 1H/ 1H1
CTVM-2 2L/ 2H/ 2H1
CTVM-3 3L/ 3H/ 3H1/ 2H2/ 3H3
In the following chapters of this manual you will find only the short model codes.
On the M-1, M-2, M-3 models the whole measurement range is split into several sub ranges (L, H, H1 etc.).
thermoMETER CTVideo
Measurement range
485 to 2200 °C
250 to 2000 °C
50 to 1800 °C
spectral typical applications
response
1 µm metals and ceramic surfaces
1,6 µm metals and ceramic surfaces
2,3 µm metals at low object
temperatures (from 50 °C)
