Outputs and Inputs

Analog Output

This output is used for the object temperature. The selection of the output signal can be done via the
programming keys [► Operating]. The software allows the programming of output channel 1 as an alarm
output.
Output signal Range
Voltage 0 ... 5 V
Voltage 0 ... 10 V
Current 0 ... 20 mA
Current 4 ... 20 mA
Thermocouple TC J
Thermocouple TC K
thermoMETER CTVideo
Connection pin on
CTVideo board
OUT-mV/mA
OUT-mV/mA
OUT-mV/mA
OUT-mV/mA
OUT-TC
OUT-TC
According to the chosen output signal there are
different connection pins on the mainboard
(OUT-mV/mA or OUT-TC).
