u 0.0 Setup of the Lower limit of temperature range. The minimum difference between lower
and upper limit is 20 K. If you set the lower limit to a value ≥ upper limit the upper limit will be
adjusted to [lower limit + 20 K] automatically.
n 500.0 Setup of the Upper limit of the temperature range. The minimum difference between
upper and lower limit is 20 K. The upper limit can only be set to a value = lower limit + 20 K.
[ 0.00 Setup of the Lower limit of the signal output. This setting allows an assignment of a
certain signal output level to the lower limit of the temperature range. The adjustment range
corresponds to the selected output mode (e.g. 0 - 5 V).
] 5.00 Setup of the Upper limit of the signal output. This setting allows an assignment of a
certain signal output level to the upper limit of the temperature range. The adjustment range
corresponds to the selected output mode (e.g. 0 - 5 V).
U °C Setup of the Temperature unit [°C or °F].
Setup of the Lower alarm limit. This value corresponds to Alarm 1 [► Alarms/ Visual
| 30.0
Alarms] and is also used as threshold value for relay 1 (if the optional relay board is used).
Setup of the Upper alarm limit. This value corresponds to Alarm 2 [► Alarms/ Visual
|| 100.0
Alarms] and is also used as threshold value for relay 2 (if the optional relay board is used).
