Sensor head Calibration Code
Every sensor has a specific calibration code, which is printed on the sensor. For a correct temperature
measurement and functionality of the sensor this calibration code must be stored into the controller.
The calibration code consists of five blocks with 4 characters each.
EKJ0 – 0OUD – 0A1B – A17U – 93OZ
Example:
block1
For entering the code please press the Up and Down key (keep pressed) and then the Mode key.
The display shows HCODE and then the 4 signs of the first block. With Up and Down each sign can be
changed, Mode switches to the next sign or next block.
After you have modified the sensor code a reset is necessary to activate the change.
[► Operating]
thermoMETER CTVideo
block2 block3 block4 block5
You will find the calibration code on a label fixed on
the sensor. Please do not remove this label or make
sure the code is noted anywhere.
