- Page 1 Instruction Manual thermoMETER...
- Page 2 Infrared sensor MICRO-EPSILON MESSTECHNIK GmbH & Co. KG Königbacher Strasse 15 94496 Ortenburg / Germany Tel. +49 (0) 8542 / 168-0 Fax +49 (0) 8542 / 168-90 info@micro-epsilon.de www.micro-epsilon.com Certified acc. to DIN EN ISO 9001: 2008...
-
Page 3: Table Of Contents
Handling................................. 17 Measurement Functions ..........................18 Display Backlight ............................20 Laser Sighting ..............................21 Optics ................................22 Setup Menu 1 .......................... 24 Emissivity Setting ............................24 High Alarm ..............................26 Low-Alarm ..............................27 Long-Term Measurement (Lock Mode) ......................28 thermoMETER LS... - Page 4 Saving of Data ..........................54 10.10.5 Opening of Files ........................... 55 10.10.6 Diagram Settings .......................... 55 10.10.7 Measurement Configuration ......................56 10.10.8 Device Setup ..........................57 10.10.9 Device Information........................58 Instructions for Operation...................... 59 11.1 Cleaning ................................. 59 11.2 Troubleshooting ............................. 59 thermoMETER LS...
- Page 5 Determination of Unknown Emissivity ......................61 13.3 Characteristic Emissivities ..........................62 Warranty ..........................63 Service, Repair ........................64 Decommissioning, Disposal ....................64 Appendix Factory Default Settings ......................65 Emissivity Table Metals ......................66 Emissivity Table Non Metals ....................68 thermoMETER LS...
- Page 6 LS...
-
Page 7: Safety
> Damage to or destruction of the infrared sensor The power supply must not exceed the specified limits. > Damage to or destruction of the infrared sensor Protect the USB cable against damage. > Damage to the infrared sensor, failure of the measuring device thermoMETER LS Page 7... - Page 8 > Damage to or destruction of the infrared sensor Don’t leave the unit on or near objects of high temperature. > Faulty measurement Avoid abrupt changes in ambient temperature. If this occurs, allow 20 minutes for thermal stabilization. > Faulty measurement thermoMETER LS Page 8...
-
Page 9: Notes On Ce Identification
Safety Notes on CE Identification The following applies to the thermoMETER LS: - EU directive 2004/108/EC - EU directive 2011/65/EC, “RoHS“ category 9 Products which carry the CE mark satisfy the requirements of the quoted EU directives and the European standards (EN) listed therein. -
Page 10: Proper Use
Safety Proper Use - The thermoMETER LS is designed for use in industrial and laboratory areas. It is used for non-contact temperature measurement. - The system may only be operated within the limits specified in the technical data, see Chap. 2.. -
Page 11: Technical Data
Technical Data Technical Data Model thermoMETER LS Temperature range IR -35 ... 900 °C (-30 ... 1650 °F) Temperature range probe -35 ... 900 °C (-30 ... 1650 °F) Temperature unit °C/ °F (switchable) Spectral range 8 … 14 μm... - Page 12 Technical Data Model thermoMETER LS Alarm functions High and Low alarm, audible and visual Emissivity/ Gain 0.100 ... 1.100 (adjustable) Interface Input t/c type K Data logger 100 measurement protocols with time stamps, 4 digit material and location names (editable)
-
Page 13: Delivery
Delivery Delivery Unpacking 1 thermoMETER LS infrared sensor 2 Batteries (type AA) 1 t/c insertion probe type K 1 USB interface cable 1 Software 1 Pouch 1 Hard case 1 Instruction manual Check the delivery for completeness and shipping damage immediately after unpacking. -
Page 14: Operation
Orientation as shown inside the compartment. Close the cover lid in reverse order. The infrared sensor thermoMETER LS is already equipped with batteries. They are protected with a plastic strip against discharge during the transport. Please remove the plastic strip before use. -
Page 15: Control And Display Elements
Control and Display Elements Fig. 3 Control and display elements Precision glass optics Optics toggle switch SF/ CF Tripod mount Trigger Display Up and Down buttons Mode (I and II) buttons Handle and battery compartment USB interface T/c input thermoMETER LS Page 15... -
Page 16: Display
Main display IR-temperature and unit (°C/ °F) HOLD, emissivity, probe temperature, Tamb-value, material and location Lower display name Mode I I Mode II Λ Assignment of buttons Bar graph display Up and Down buttons Mode buttons thermoMETER LS Page 16... -
Page 17: Measurement
If the laser is activated the true size and location of the measurement spot will be shown on the object sur- face. The temperature of the object is shown in the display (2). The thermoMETER LS can also be used in vertical position, i.e. measurement downwards, see Fig. -
Page 18: Measurement Functions
The temperature will be displayed for 7 seconds after the trigger is released. The display shows HOLD, 9. The device automatically switches off after this time, if no button is pressed. Fig. Fig. 9 View HOLD thermoMETER LS Page 18... - Page 19 To recall this value please press (in the switched off condition) the I or II button. The unit will be set into the HOLD mode. In the emissivity menu the last measured temperature value can be corrected afterwards by changing the emissivity. thermoMETER LS Page 19...
-
Page 20: Display Backlight
Then press the I button to activate/ deactivate the display backlight, see Fig. Fig. 11 Symbol display backlight The symbol in the display flashes to confirm. Default setting: 1) This function is not available in the Flip mode. thermoMETER LS Page 20... -
Page 21: Laser Sighting
Avoid indirect exposure via reflec- Fig. 14 Laser label tive surfaces! During operation the pertinent regulations acc. to DIN EN 60825-1: 2007 on “radiation safety of laser equip- ment” must be fully observed at all times. thermoMETER LS Page 21... -
Page 22: Optics
Measurement Optics The thermoMETER LS has switchable optics. The two possible operating modes are indicated as SF mode (Standard Focus) and CF mode (Close Focus). In the SF mode (standard operating mode) objects ≥ 16 mm can be measured. The measurement spot will be exactly marked with the patented crosshair laser, i.e. - Page 23 The measured area of the object (spot size) depends on the distance. For a correct measurement the spot size should have at least the same size like the object or should be smaller than that at all times. thermoMETER LS Page 23...
-
Page 24: Setup Menu 1
It can range between 0 and 1 (0 and 100 %), see Chap. Setting range: 0,100 ... 1,100 (values > 1,000 = amplification) Default setting: 0,950 ⇒ ε ⇒ ⇒ ε HOLD II ⇒ flashes Λ INCREASE ⇒ ⇒ ε DECREASE thermoMETER LS Page 24... - Page 25 Setup Menu 1 Fig. 17 Emissivity symbol Fig. 18 Display measurement function emissivity setting thermoMETER LS Page 25...
-
Page 26: High Alarm
⇒ Λ HOLD H flashes INCREASE VALUE ⇒ V ⇒ DECREASE VALUE ⇒ II ⇒ ⇒ alarm symbol [beside H] on/ off CTIVATION EACTIVATION Fig. 19 Symbol high alarm Fig. 20 Display measurement function high alarm thermoMETER LS Page 26... -
Page 27: Low-Alarm
⇒ HOLD 2x I L flashes Λ INCREASE VALUE ⇒ ⇒ DECREASE VALUE ⇒ ⇒ ⇒ alarm symbol [beside L] on/ off ACTIVATION DEACTIVATION Fig. 21 Symbol low alarm Fig. 22 Display measurement function low alarm thermoMETER LS Page 27... -
Page 28: Long-Term Measurement (Lock Mode)
⇒ ⇒ ⇒ 2x I HOLD+Lock Trigger starting Measurement mode + Lock ⇒ Trigger starting Measurement mode + Lock Fig. 23 Symbol long-term measure- Fig. 24 Display measurement function long-term measurement ment (Lock Mode) (Lock Mode) thermoMETER LS Page 28... - Page 29 The data logger functions are also available in the Lock mode, see Chap. 10.6. For a long-term temperature measurement of an object it is recommended to mount the unit on a tripod, see Fig. Fig. 25 Tripod for thermoMETER LS thermoMETER LS Page 29...
-
Page 30: Setup-Menu 2
HOLD⇒ II ⇒4x I ⇒2. Menu The procedure is the same as described in the setup menu 1, see Chap. 6.: Trigger ⇒S ⇒Measurement mode I ⇒S ⇒next menu item Fig. 26 Display setup menu 2 thermoMETER LS Page 30... -
Page 31: Temperature Unit
With this function you can switch the temperature unit in the display between °C and °F. Setting range: °C/ °F Default setting: °C ⇒ ⇒ Temperature unit flashes ⇒ ⇒ Λ 2. Menu °C/ °F ⇒ ⇒ °C/ °F Fig. 27 Symbol temperature unit Fig. 28 Display measurement function temperature unit thermoMETER LS Page 31... -
Page 32: Buzzer
(confirmation by pressing Mode , Up and Down button) will remain On. Setting range: On/ Off Default setting: ⇒ ⇒ ⇒ ⇒ ⇒ Buzzer symbol flashes Λ 2. Menu ON/ OFF ⇒ ⇒ Fig. 29 Symbol buzzer Fig. 30 Display measurement function buzzer thermoMETER LS Page 32... -
Page 33: Flip Display
Flip Display The thermoMETER LS has a so called Flip display (turn around display). As the unit can be used in horizontal and in vertical position (preferably in combination with the CF mode), the ability to switch allows a comfor- table operation in both positions. -
Page 34: Ambient Temperature Compensation
To compensate this impact you can use this function to enter a temperature value for the ambient radiation (Tamb): Setting range: -35 ... 900 °C Default setting: Deactivated An activation of this function on the thermoMETER LS for the first time is only possible with the supplied software, see Chap. 10.10.8. ⇒ ⇒ ⇒ ⇒... - Page 35 RES flashes ESET ⇒ ⇒ HOLD ⇒ ⇒ Trigger Measure mode If, in addition, a thermocouple probe is connected, the lower display will toggle between emissivity, t/c probe temperature and Tamb value, see Fig. 36, see Chap. thermoMETER LS Page 35...
-
Page 36: Reset
Trigger Measure mode Fig. 37 Symbol reset Fig. 38 Display measurement function reset The stored values in the data logger will not be deleted with the Reset function. 1) depends on the status of Tamb function thermoMETER LS Page 36... -
Page 37: Data Logger
Data Logger Data Logger The thermoMETER LS has an internal data logger with a maximum capacity of 100 measurement protocols. Every protocol contains the following values, which can also be opened on the device: Position number (P 00...P 99), object temperature, MAX-, MIN-, AVG- and DIF value, emissivity, probe tem-... -
Page 38: Material And Position Names
⇒ II ⇒ description flashes ⇒ Λ ⇒SURF, ..., GLAS, ..., PVC, ... Disc symbol + choosen position [Pxx] ⇒ V ⇒PVC, ..., GLAS, ..., SURF, ... ⇒ I ⇒SAVE You can also define own descriptions. The following character set can be used: [A...Z] [0...9] [-/<>] [empty] thermoMETER LS Page 38... -
Page 39: Data Logger Recall
P -1⇐ V ⇐P xx⇒ Λ ⇒P +1 TObj Material and location name ⇑ ⇓ ⇑ TObj Emissivity ⇑ ⇑ ⇓ Λ Trigger + Λ ⇓ ⇓ MAX/ TObj TObj/ MAX/ MIN/ AVG/ DIF TExt [probe temperature] thermoMETER LS Page 39... - Page 40 Data Logger To leave the data logger mode please press again the Trigger and V simultaneously. If no button is pressed, the unit switches off after approx. 30 s. thermoMETER LS Page 40...
-
Page 41: Thermocouple Probe
Thermocouple Probe The thermoMETER LS has an input for thermocouple probes. You will find the connection at the end of the handle, see Chap. 4.2. You can connect the supplied insertion probe as well as any other t/c probe type K. -
Page 42: Software Ir Connect
- USB interface - Hard disc with at least 30 MByte free space - At least 128 MByte RAM - CD-ROM drive 10.3 Main Features - Download of logger data - Display and record of temperature trends thermoMETER LS Page 42... -
Page 43: Connection To The Computer
The connection cable supplied is not a standard USB cable! As long as the LS is connected to your computer it will be powered via the USB interface. In this case oper- ation is also possible if no batteries are inside the unit. At digital communication the unit display shows the HOLD –mode but the unit is measuring continuously and is sending temperature data via the interface to the... -
Page 44: Language
Software IR Connect computer, see Chap. 10.9. If you cannot establish a communication in spite of correct connection between thermoMETER LS and com- puter please choose the correct COM-Port under Setup > Interface menu. If the USB adapter cable is connected this port is marked (Infrared Thermometer Adapter), see Fig. -
Page 45: Data Logger Functions
To download the logger data from the unit please press the Logger -button in menu Measurement > Download logger data. All data from the logger will be displayed in an extra window as a table, see Fig. Fig. 49 Symbol or button data Fig. 50 Screen data logger functions logger function thermoMETER LS Page 45... - Page 46 Logger temperatures, on which the set Hi-Alarm value has been exceeded, will be shown in the table red and bold, see Fig. Logger temperatures, on which the set Lo-Alarm value has been exceeded, will be shown in the table blue and bold, see Fig. thermoMETER LS Page 46...
-
Page 47: Time Stamp
10.7 Time Stamp If you store data inside your thermoMETER LS for the first time (after insertion of the batteries), an internal timer will be started automatically. When connected to a computer the timer will be synchronized with the computer time. Thus, every logger entry is stored with date and time of the measurement. -
Page 48: Material And Location Names
If a wrong input is made (no character/ more than 4 characters/ invalid character) the position number in the table appears red and the table cannot be closed with OK. Fig. 53 Symbol material and position names Fig. 54 Screen material and position names thermoMETER LS Page 48... -
Page 49: Digital Displays
Fig. 56 Buttons in the display material and location names 10.9 Digital Displays If the thermoMETER LS is connected to your computer and you start the software, the current temperature TObj will be shown top right as digital display, see Fig. -
Page 50: Diagram Functions
To start a measurement, please press the Start button in the tool bar of Measurement menu. Fig. 59 Button Start Fig. 60 Screen digital displays Control elements of the time axis Scroll bar Zoom in (increase) Zoom out (decrease) Whole range H: Hold/ C: Continue Fig. 61 Screen time axis detail thermoMETER LS Page 50... - Page 51 During the stopped status any parts of the diagram can be selected with the Time scroll bar. With the zoom in-button + these parts can be stretched (enlarged) and with the zoom out-button – clinched (minimized). thermoMETER LS Page 51...
-
Page 52: Scaling Of The Temperature Axis
A manual scaling can be done at any time using the control elements of the temperature axis. Activate the desired option by the control elements of the temperature axis respectively in the menu Di- agram. thermoMETER LS Page 52... -
Page 53: Stop Measurement
To stop the current measurement please press the Stop button in the menu Measurement. The Save button in menu File > Save as opens an explorer window to select destination and file name [file type: *.dat]. thermoMETER LS Page 53... -
Page 54: Saving Of Data
If none of the options is activated, a new measurement will be started after termination of one measure- ment and pressing of the Start button. In this case the former data are deleted! Fig. 66 Symbol Save Fig. 67 Screen storage security thermoMETER LS Page 54... -
Page 55: Opening Of Files
Color Time frame on the x-axis, which should be displayed at the beginning of a measure- Initial time ment. Fig. 68 Buttons in the display diagram settings Fig. 69 Symbol Open Fig. 70 Screen Diagram settings thermoMETER LS Page 55... -
Page 56: Measurement Configuration
Fig. 72 Screen measurement configuration A change of the parameter Max. data count will have influence on the Memory and Recording time. A change of the parameter Recording interval will have influence on the Recording time only. thermoMETER LS Page 56... -
Page 57: Device Setup
Fig. 75 Screen device setup The first activation of Ext. Ambient Temp. will initiate this feature inside the thermoMETER LS device. From this time the feature will appear in the Setup Menu 2 on the device, also if deactivated again in the device setup, see Chap. -
Page 58: Device Information
Revision number of the internal hardware Hardware Rev. Serial number of the device Serial No. Measurement range (IR) IR Temperature range Fig. 77 Buttons in the display device information Fig. 78 Symbol Info Fig. 79 Screen device information thermoMETER LS Page 58... -
Page 59: Instructions For Operation
Battery symbol is on or flashing. Low batteries Check/ replace batteries. Blank display Empty batteries Check/ replace batteries immediately. Laser does not work. Low batteries/ Laser deactivated See above. Activate the laser. thermoMETER LS Page 59... -
Page 60: Functional Principle
The specifications of the lens decisively determine the optical path of the infrared thermometer, which is char- acterized by the ratio Distance-to-Spot-size. The spectral filter selects the wavelength range, which is relevant for the temperature measurement. The detector in cooperation with the processing electronics transforms the emitted infrared radiation into electrical signals. thermoMETER LS Page 60... -
Page 61: Emissivity
Afterwards, determine the temperature of a directly adjacent area and modify the emissivity until the measured value corresponds to the temperature of the colored surface. On all three methods the object temperature must be different from the ambient temperature. thermoMETER LS Page 61... -
Page 62: Characteristic Emissivities
- Measuring angle - Geometry of the surface (flat, convex, concave) - Thickness of the material - Constitution of the surface (polished, oxidized, rough, sandblast) - Spectral range of the measurement - Transmissivity (e.g. with thin films) thermoMETER LS Page 62... -
Page 63: Warranty
The warranty period lasts 12 months following the day of shipment. Defective parts, except wear parts, will be repaired or replaced free of charge within this period if you return the device free of cost to MICRO-EPSILON. This warranty does not apply to damage resulting from abuse of the equipment and devices, from forceful handling or installation of the devices or from repair or modifications performed by third parties. -
Page 64: Service, Repair
Please contact your local distributor. Decommissioning, Disposal Disconnect the USB cable from the infrared sensor. The thermoMETER LS is produced according to the directive 2011/65/EU, “RoHS“. Do the disposal according to the legal regulations (see directive 2002/96/EC). thermoMETER LS Page 64... -
Page 65: Appendix
Optics High alarm 900 °C/ deactivated Low alarm -35 °C/ deactivated Temperature unit °C Lock Buzzer Laser Display backlight Display turn Auto The Reset function will set the unit back to these default values (exception: optics). thermoMETER LS Page 65... -
Page 66: Emissivity Table Metals
0.15 Inconel Electro polished 0.3 - 0.6 Sandblast 0.7 - 0.95 Oxidized 0.05 - 0.2 Iron Non oxidized 0.5 - 0.7 Rusted 0.5 - 0.9 Oxidized Forged, blunt Non oxidized Iron, casted Oxidized 0.6 - 0.95 thermoMETER LS Page 66... - Page 67 0.1 - 0.8 Rustless 0.4 - 0.6 Heavy plate 0.7 - 0.9 Cold-rolled 0.7 - 0.9 Oxidized 0.05 Non oxidized 0.05 - 0.2 Titanium Polished 0.5 - 0.6 Oxidized 0.03 – 0.1 Wolfram Polished 0.02 Zinc Polished Oxidized thermoMETER LS Page 67...
-
Page 68: A 3 Emissivity Table Non Metals
Carborundum Ceramic 0.95 Concrete 0.95 Glass 0.85 Grit 0.95 Gypsum 0.8 - 0.95 0.98 Limestone 0.98 Paint Non alkaline 0.9 – 0.95 Paper Any color 0.95 Plastic > 50 μm Non transparent 0.95 Rubber 0.95 Sand thermoMETER LS Page 68... - Page 69 Anhang | Emissivity Table Metals Material Typical Emissivity Snow Soil 0.9 – 0.98 Textiles 0.95 Water 0.93 Wood Natural 0.9 - 0.95 thermoMETER LS Page 69...
