Water Cooled Housing - MICRO-EPSILON CTVM-1L Instruction Manual

Water Cooled Housing

Water cooled housing [TM-W-CTL]
Hose connection: 6x8 mm
Thread (fitting): G 1/8 inch
The sensor can be used at ambient temperatures up to 70 °C without cooling. For applications, where the
ambient temperature can reach higher values, the usage of the optional water cooled housing is
recommended (operating temperature up to 175 °C). The sensor should be equipped with the optional high
temperature cables (operating temperature up to 180 °C).
thermoMETER CTVideo
To avoid condensation on the optics an air
purge collar is recommended.
21
