3

Initial Start-Up

3.1

Switching the Instrument on and Testing the Batteries

START
The instrument can be switched on by pressing any key.
Five battery symbols ranging from depleted to fully charged continuously
indicate the current battery level in the main menu.
If the above message appears during initial start-up – non-defined data in
memory – the contents of the memory must be entirely deleted.
GMC-I Messtechnik GmbH
3.2

Installing and Replacing Batteries

New batteries must be installed before initial start-up, or when only one
solid segment remains in the battery symbol.
The contents of the memory remain intact during battery replacement
(back-up time: approximately 5 to 10 minutes).
!
Attention!
The instrument must be disconnected from the measuring circuit
(mains) at all poles before the battery compartment is opened.
Pull the test plug!
Four 1.5 V baby cells in accordance with IEC LR14 are required for
operation of the PROFiTEST
Rechargeable NiCd or NiMH batteries may be used as well. Be absolutely
sure to refer to chapter 12.2, page 36, regarding the charging cycle and
the charging adapter.
Always replace the batteries in complete sets.
Dispose of batteries in an environmentally sound fashion.
➭
Loosen the two slotted screws at the battery compartment cover on
the housing rear panel and remove the cover.
➭
Insert four 1.5 V baby cells making certain the they are poled in
accordance with the symbols. Insert the two batteries which are half
covered by the housing first.
➭
Replace the cover and retighten the screws.
!
Attention!
The instrument may not be operated if the battery compartment
cover has not been installed and properly tightened!
+
3.3

User Guide in a Different Language

By performing a software update it is possible to load another language
for the user guide than the one included in the scope of supplies. Any lan-
guage currently available is proposed for choice when WinProfi is being
installed, see chapter 3.5.
®
C. Use alkaline-manganese batteries only.
7
