Connect the NA 102 battery charger to the charging socket with the
3.5 mm jack plug. Set the voltage selector switch at the NA 102 to 9 V.
Switch the test instrument on.
The test instrument recognizes the fact that a battery charger has been
connected and starts the charging cycle. The 5 segments of the battery
symbol are continuously displayed in a sweeping pattern from left to right
for the entire duration of the charging cycle.
Depleted batteries require a charging cycle of approximately 14 hours. If
the batteries are exhausted to a great enough extent, the test instrument
can no longer be switched on. If this is the case, leave the test instrument
connected to the activated battery charger for about 30 minutes, and then
proceed as described above.

12.3 Fuses

If a fuse has blown due to an overload, an appropriate error message
appears at the LCD. However, the instrument's voltage measuring ranges
are still functional.
Replacing Fuses
The fuses can be accessed easily from the outside of the instrument, and
are located to the left of the mains connector cable.
➭
Remove the cap for the respective fuse with the help of a suitable tool
(e.g. screwdriver) by pressing and turning counterclockwise.
!
Attention!
Incorrect fuses may cause severe damage to the test instrument.
Only original fuses from GMC-I Messtechnik GmbH assure the re-
quired protection by means of suitable breaking characteristics
(article no. 3-578-164-01). Bridging or repairing fuses is prohib-
ited! The instrument may be damaged if fuses with other current
ratings, blowing or breaking characteristics are used!
➭
Remove the defective fuse and replace it with a new replacement
fuse. Replacement fuses are located in the battery compartment.
➭
Insert the new fuse and the cap together, and lock into place by
turning clockwise.
➭
Replace the battery compartment cover and secure it with the screws.
GMC-I Messtechnik GmbH

12.4 Housing

No special maintenance is required for the housing. Keep outside sur-
faces clean. Use a slightly dampened cloth and/or a special purifier for
synthetic material for cleaning. Avoid the use of cleansers, abrasives and
solvents.
!
Attention!
For the following reasons, the housing may not be opened by the
operator:
– Unexpected problems may occur during reassembly.
– Sealing requirements are no longer fulfilled.
Opening of Equipment / Repair
The equipment may be opened only by authorized service personnel to
ensure the safe and correct operation of the equipment and to keep the
warranty valid.
Even original spare parts may be installed only by authorized service per-
sonnel.
In case the equipment was opened by unauthorized personnel, no war-
ranty regarding personal safety, measurement accuracy, conformity with
applicable safety measures or any consequential damage is granted by
the manufacturer.
Device Return and Environmentally Compatible Disposal
The instrument is a category 9 product (monitoring and control instrument)
in accordance with ElektroG (German Electrical and Electronic Device
Law). This device is subject to the RoHS directive. Furthermore, we make
reference to the fact that the current status in this regard can be accessed
on the Internet at www.gossenmetrawatt.com by entering the search term
WEEE.
We identify our electrical and electronic devices (as of August
2005) in accordance with WEEE 2012/19EU and ElektroG with
the symbol shown to the right per DIN EN 50419. These devices
may not be disposed of with the trash. Please contact our ser-
vice department regarding the return of old devices (see chapter 13).
