- Page 1 Operating Instructions Firmware Update Tool Software Program for Updating the Firmware for the Test Instruments 3-349-793-03 SECUTEST (10)/P SECULIFE ST (25) & PROFITEST (AC) BASE RIME 5/10.17...
-
Page 2: Table Of Contents
Supported Devices procedure are explained in chapter 3. The Firmware Update Tool supports the following test instru- ments: SECUTEST BASE Attention! SECUTEST BASE10 Prior to performing a firmware update, we strongly rec- ommend that you save the structures you have created... -
Page 3: Installation And Program Sequence
Installation and Program Sequence The Firmware Update Tool for updating the firmware version of your test instrument is available for download from our homepage: http://www.gossenmetrawatt.com → Products → Software → Software for Testers → Utilities→ Firmware Update Tool or in the myGMC section The zip file must be unzipped into a file directory. - Page 4 ➭ At last, click on „Finish“ to terminate the setup wizard. The associated desktop icon is created if you tick the appropriate box and after clicking on „Next“. ➭ Continue by clicking on „Install“. A progress bar is shown. GMC-I Messtechnik GmbH...
-
Page 5: Starting The Firmware Update Tool
Starting the Firmware Update Tool 3.2.1 Testing the Files on your PC and in the Test Instrument The update process is automatically launched when installing the Firmware Update Tool for the first time. However, if you wish to update several test instruments succes- sively with the latest firmware, the software, once installed, can be started by double-clicking on the following icon in the menu bar or on the desktop. - Page 6 ➭ Quit the current applications before continuing the update. Select either all applications or the one shown on the display in each case and press the button „Stop selected applica- tions“. As soon as the program has recognized the connected test instrument, the characteristics such as device type and serial number as well as the firmware version are shown for verification purposes.
-
Page 7: Starting The Firmware Update
3.2.2 Starting the Firmware Update ➭ If you confirm the query with „Yes“, the actual firmware update process in the test instrument starts. Attention! During the firmware update via the USB interface of the PC, the interface cable may not be disconnected. Attention! The test instrument may not be disconnected from the power supply during firmware update. -
Page 8: Product Support
Product Support When you need service, please contact: GMC-I Messtechnik GmbH Product Support Hotline Phone +49 911 8602-0 +49 911 8602-709 E-Mail support@gossenmetrawatt.com Copyright © 2017 GMC-I Messtechnik GmbH Duplication and/or forwarding of this document to third parties, as well as the use or transmission of its contents, are prohibited with- out prior express consent.
