4 Appendix
; -- DHCP Server Configuration --
subnet subnetea 0 network 172.24.0.0 255.255.0.0
subnet subnetea 0 bootfile fwethant.img
subnet subnetea 0 next-server 172.24.78.29
subnet subnetea 0 router 172.24.78.29
;
enable
;
host eth-ant 0 ethernet 00-a0-26-53-29-02
host eth-ant 0 fixed-ip 172.24.78.31
host eth-ant 0 option 43 asc antenna&sipport=5060&localphone=607081119
Router 2:
protocol dhcp
; -- DHCP Configuration --
server
; -- DHCP Server Configuration --
subnet subnetea 0 network 172.24.0.0 255.255.0.0
subnet subnetea 0 bootfile fwethant.img
subnet subnetea 0 next-server 172.24.78.30
subnet subnetea 0 router 172.24.78.30
;
enable
;
host eth-ant 0 ethernet 00-a0-26-53-29-03
host eth-ant 0 fixed-ip 172.24.78.32
host eth-ant 0 option 43 asc antenna&sipport=5060&localphone=607326598

4.2 LEDs

The device has several LEDs and their meaning is as follows:
LED
POWER
WWAN
Ethernet Connector
STATUS
28
STATUS DESCRIPTION
ON/OFF When this is lit up, the device is receiving power.
OFF Error in the WWAN module. 3G communications are not possible.
Flashing Green (slow) The SIM card hasn't been detected or the PIN is incorrect.
Flashing Green (fast) The module cannot register in the network.
Steady Green Communications at the PPP layer.
ON/OFF The left hand LED lights up in yellow when there is link level and the
right hand one flashes in green when there is data communication.
Steady Red Error in the WWAN module. 3G communications are not possible.
• Check that the module is correctly connected.
• Check that it has the appropriate software.
• Look to see if the WWAN LED is lit up.
Flashing Red The WWAN module is operating correctly but the device hasn't got
an IP address yet.
• Check the status of the Ethernet connector LEDs.
• The device has access to the DHCP server.
• Follow the instructions given in the "Monitoring" section.
Flashing yellow The device has received the IP address but hasn't managed to es-
