remove this bolt
PCIII USB EX
connector
i818-511EX
U
SE THE
unplug this
M
ODELS
connector
The ignition must be turned OFF before
installation.
1
Remove the seat.
2
Remove the right hand side cover.
3
Unplug the stock wiring harness from the ECM
as shown in Figure F.
4
Remove the bolt securing the ECM tray as
shown in Figure F.
5
Remove the ECM tray and lift the ECM and tray
out of the way.
6
Loosen the positive cable on the battery and
rotate it 90 degrees as shown in Figure G.
Tighten the cable in this new position.
7
Attach the male connector from the
PCIII USB EX to the stock wiring harness.
8
Position this connection in front of the battery
as shown in Figure H and Figure I.
F
I
OLLOWING
NSTRUCTIONS FOR
2008 Harley Davidson Touring - PCIII USB EX - 4
ABS
