Dynojet Power Commander III Installation Instructions page 3

PCIII USB EX
connector
i818-511EX
10 Reinstall the ECM and tray back into the stock
PCIII USB EX
position.
connector
11 Attach the connector from the PCIII USB EX to
the stock ECM as shown in Figure D.
12 Attach the connector from the PCIII USB EX to
the stock wiring harness as shown in Figure E.
13 Secure the connectors in place with the
supplied zip tie.
14 Using the supplied velcro, install the
PCIII USB EX to the side of the battery box as
shown in Figure E.
Make sure to use the supplied alcohol swab to
clean the battery box and the PCIII USB EX
before attaching the PCIII USB EX.
15 Reinstall the ECM and the ECM tray using the
bolt removed earlier.
stock
connector
16 Reinstall the right hand side cover and the seat.
17 Insert the cd provided into your computer's
cd-rom drive.
18 Follow the on-screen instructions to install the
PCIII USB EX software.
19 Visit www.powercommander.com to download
software tutorials and the latest maps.
Note: This bike has fly-by-wire throttle. Make
sure when setting the throttle position the bike
is fully warmed up. You can not set the OPEN
throttle setting in the software unless the RPM
is above 3000 RPM.
2008 Harley Davidson Touring - PCIII USB EX - 3
