Queue Settings Menu

The Queue Settings menu lets you configure QoS behavior as either strict priority or
weighted priority.
Strict priority – allows delay-sensitive data such as voice to be sent before packets in
other queues.
Weighted priority – lets you assign each queue with a certain weight indicating the
amount of guaranteed capacity, with high priority packets served before any low priority
packets.
To access the Queue Settings menu, click QOS in the menu bar and then click the Queue
submenu in the menu bar. Figure 34 shows an example of the menu.
Note: The Queue submenu is not available in the menu bar if Enable QOS
Module is not checked in the QoS Settings menu (see page 62).
SMCD3GN2 Wireless Cable Modem Gateway Administrator Manual
錯誤! 尚未定義樣式。
Figure 34. Queue Settings Menu
69
