SMC Networks SMCD3GN3 Administrator User Manual page 52

Option
IP Address
IP Subnet Mask
Domain Name
As WAN IP
IP Address
IP Subnet Mask
Domain Name
Enable DHCP Server
Lease Time
Assign DNS Manually
Primary DNS
Secondary DNS
Start IP
End IP
Start IP
End IP
SMCD3GN2 Wireless Cable Modem Gateway Administrator Manual
錯誤! 尚未定義樣式。
Table 9. LAN Settings Menu Options
Pubic LAN IP
IP address of the Gateway's private LAN settings. Default IP address is 192.168.0.1. if you
change this setting, the Gateway reboots after displaying a message.
Subnet mask of the Gateway's private LAN settings. Default subnet mask is 255.255.255.0.
Domain name of the Gateway's private LAN settings.
Check this box if you want to use the static public LAN IP address for the WAN IP address.
Private LAN IP
IP address of the Gateway's private LAN settings. Default IP address is 192.168.0.1. if you
change this setting, the Gateway reboots after displaying a message.
Subnet mask of the Gateway's private LAN settings. Default subnet mask is 255.255.255.0.
Domain name of the Gateway's private LAN settings.
Enables or disables the DHCP server to allow automatic allocation of IP addresses to LAN
client PCs.
Checked = DHCP server is enabled. (default)
•
Unchecked = DHCP server is disabled.
•
Amount of time a DHCP network user is allowed connection to the Gateway with their current
dynamic IP address. Default is One Week. This option is available when Enable DHCP
Server is checked.
Enables or disables the DHCP server to allow automatic allocation of primary and secondary
IP addresses for DSN servers on the LAN.
Checked = use static IP addresses for primary and secondary DNS servers. If checked,
•
enter the IP addresses of the primary and secondary DNS server in the Primary DNS and
Secondary DNS fields.
Unchecked = allocate IP addresses for primary and secondary DNS servers automatically.
•
(default)
Static IP address of the primary DNS server. This option is available when Assign DNS
Manually is checked.
Static IP address of the secondary DNS server. This option is available when Assign DNS
Manually is checked.
Private IP Address Pool
Starting IP address range for the pool of allocated for private IP addresses.
Ending IP address range for the pool of allocated for private IP addresses.
PPTP IP Address Pool
Starting IP address range for the pool of allocated for point-to-point tunneling protocol (PPTP)
IP addresses.
Ending IP address range for the pool of allocated for PPTP IP addresses.
52
Description
