PC-CARD-D24/CTR3 User's Guide
Crystal oscillator

Power consumption

+5V operating

Miscellaneous

+5 Volts DC

Environmental

Operating temperature range
Storage temperature range
Humidity

Connector and pin out

Connector type
Compatible cables
Compatible accessory products
Frequency:
Frequency accuracy:
Miscellaneous:
Table 3. Power consumption specifications
45 mA typical, 65 mA max
Table 4. Miscellaneous specifications
Available at I/O connector (+5V Power)
Protected by resettable fuse:
Hold current:
Trip current:
Trip and recovery time:
Table 5. Environmental specifications
0 to 70 °C
-40 to 100 °C
0 to 95% non-condensing
Table 6. Connector specifications
50-pin connector
CPCC-50F-39: 50-pin Micro connector to 50-pin female IDC, one-meter cable
(39 inches).
CPCC-50M-4: 50-pin Micro connector to 50-pin male IDC, 4 inch adapter cable.
and
C50FF-x: 50-pin IDC female to female cable. x = length in feet.
CIO-MINI50
CI-SPADE50
CIO-TERM100
SCB-50
SSR-RACK24
CIO-ERB24
CIO-SERB24
17
10 MHz
50 ppm
Available (divided by 10) at user connector (1 MHz Out)
350 mA
700 mA
100 mS
Specifications
