- Page 1 PC-CARD-DAC08 Analog Outputs & Digital I/O User’s Manual Revision 1 March, 2001 (C) Copyright 2001, Measurement Computing Corporation...
- Page 2 IBM, PC, and PC/AT are trademarks of International Business Machines Corp. Windows is a trademark of Microsoft Corp. All other trademarks are the property of their respective owners. Information furnished by Measurement Computing Corp. is believed to be accurate and reliable. However, no responsibility is assumed by Measurement Computing Corporation neither for its use;...
-
Page 3: Table Of Contents
3 INTERFACING ........... . 3.1 PC-CARD-DAC08 CONNECTOR ....... . . - Page 4 This page is blank.
-
Page 5: Introduction
1 INTRODUCTION The PC-CARD-DAC08 is an eight-channel, analog output control board for IBM PC compatible computers having PCMCIA-type slots. The heart of the board is an octal, 13-bit digital-to-analog converter of which only 12 bits are used for each output. -
Page 6: Installation
2 INSTALLATION 2.1 SOFTWARE Your PCM card is completely plug and play. There are no switches or jumpers to set prior to installation in your computer. InstaCal is the installation, calibration and test software supplied with the board. Refer to the Extended Software Installation Manual to install InstaCal. -
Page 7: Interfacing
26 pins of the connector. 3.1 PC-CARD-DAC08 CONNECTOR Figure 3-1 shows a PC-CARD-DAC08 case looking into the male mini-connector. The connector is mechanically keyed to insure that the cable is inserted correctly. -
Page 8: Connecting Devices To The Analog Outputs
3.6 DIGITAL INPUTS & OUTPUTS The PC-CARD-DAC08 has eight bi-directional digital I/O lines. The eight digital lines can be programmed as input or output in groups of: eight inputs, eight outputs or four inputs and four outputs. A register controls the direction of the digital I/O lines... -
Page 9: Programming & Applications
Many packaged application programs, such as SoftWIRE , have drivers for the PC-CARD-DAC08. If the package you own does not appear to have drivers you need, please fax the package name and the revision number from the install disks. We will... -
Page 10: O Address Map & Register Functions
CSS is stored in the CB.CBG file by InstaCal. After CSS is installed and a base address has been established, the PC-CARD-DAC08 is controlled by writing to and reading from the control registers. While it is possible to write your own control routines, routines have been written and are available in Universal library for DOS and Windows programming languages. - Page 11 Table 5-1. DAC Selection and Update Mode Function on Function on Base + 0, Base + 0 Read Base + 1 Write Update DAC0 & 1 Latch new D/A Value for DAC0 Update DAC0 & 1 Latch new D/A Value for DAC1 Update DAC2 &...
- Page 12 Interrupt status routines may want to read and verify this bit then clear it with a read of Base +1. INT_EN Enable external interrupt. Enable = 1. Disable = 0.
-
Page 13: Specifications
Worst case error is realized only in the unlikely event that each of the component errors are at their maximum level, and causing error in the same direction. Each PC-CARD-DAC08 is tested at the factory to ensure the board’s overall SW calibrated error does not exceed ±4.0 LSB. - Page 14 However, this again assumes that each of the errors contributes in the same direction and the ±1.8 LSB specification is quite conservative. Slew Rate ± 1.6 V/µs min Settling Time (to ½ LSB of FSR) 8.0 µs typ Current Drive ±1 mA min Output short-circuit duration Indefinite @15 mA...
- Page 15 Connector and Pin Out Connector Type: Honda 26-Pin mini D-type Connector Compatibility: Translates to 37D pinout using PC-CARD-C37F/26 cable. Main Connector: SIGNAL NAME SIGNAL NAME EXT. INTERRUPT IN DIGITAL I/O 0 DIGITAL I/O 1 DIGITAL I/O 2 DIGITAL I/O 3 DIGITAL I/O 4 DIGITAL I/O 5 DIGITAL I/O 6...
- Page 16 NOTE: If the 37-pin connector (P2) is removed from the C37F/26 cable assembly and is to be replaced by a different user’s connector, wiring of the replacement connector must adhere to the twisted-pair pairings listed in the following table. Wire Run List C3726 - P1 (Honda) to P2 (37D) Twisted Honda Pair...
- Page 17 For Your Notes...
- Page 18 For Your Notes...
- Page 19 EC Declaration of Conformity We, Measurement Computing Corporation, declare under sole responsibility that the product: PCMCIA Eight-Channel Analog Output Board with eight DIO channels. PC-CARD-DAC08 Part Number Description to which this declaration relates, meets the essential requirements, is in conformity...
- Page 20 Measurement Computing Corporation 16 Commerce Boulevard, Middleboro, Massachusetts 02346 (508) 946-5100 Fax: (508) 946-9500 E-mail: info@measurementcomputing.com www.measurementcomputing.com...
