PC-CARD-D24/CTR3 User's Guide
Figure 6 shows a map of the two methods of cabling the PC-CARD-D24/CTR3 to various screw terminal or
signal conditioning boards.
PC-CARD-D24/CTR3
PC-CARD-D24/CTR3
CPCC-50F-39
49
Key
1
50-pin female IDC connector.
Details on the CPCC-50F-39 cable are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=105&pf_id=1379.
CPCC-50M-4
OR
CPCC-50F-39
Figure 6. Connecting to screw terminal or relay boards
50
2
Figure 7. CPCC-50F-39 cable connections
TERMINALS
CIO-MINI50
CIO-SPADE 50
CIO-TERM100
C50FF-# SCB-50
TERMINALS
CIO-MINI50
CIO-SPADE 50
CIO-TERM100
SCB-50
50-pin micro connector.
Connect to the I/O connector
with the dot facing UP.
12
Installing the PC-CARD-D24/CTR3
RELAYS
SSR-RACK24
CIO-ERB24
CIO-SERB24
RELAYS
SSR-RACK24
CIO-ERB24
CIO-SERB24
50
1
Dot
on the PC-CARD
