PC-CARD-D24/CTR3 User's Guide
Pin Signal Name
1 Ext Int
2 GND
3 Int Enable
4 GND
5 CTR1 CLK
6 GND
7 CTR1 Gate
8 GND
9 CTR1 Out
10 GND
11 CTR2 CLK
12 GND
13 CTR2 Gate
14 GND
15 CTR2 Out
16 GND
17 CTR3 CLK
18 GND
19 CTR3 Gate
20 GND
21 CTR3 Out
22 GND
23 1 MHz Out
24 GND
25 A7
Table 7. Connector pin out
Pin Signal Name
26 A6
27 A5
28 A4
29 A3
30 A2
31 A1
32 A0
33 B7
34 B6
35 B5
36 B4
37 B3
38 B2
39 B1
40 B0
41 C7
42 C6
43 C5
44 C4
45 C3
46 C2
47 C1
48 C0
49 +5V
50 GND
18
