User Guide CCM-BOOGIE • High Performance Core
Bus Device
Number Number
0 31
0 31
0 31
0 31
2)
1 0
2)
3 0
1)
Depends on BIOS implementation.
2)
Bus number can vary depending on the PCI enumeration schema implemented in BIOS.

Local SMB Devices

The CCM-BOOGIE contains a few devices that are reachable via the System Management Bus (SMBus).
These are the clock generation chip, the SPD EEPROMs for the onboard memory channel or located
on the SODIMM memory module, a general purpose serial EEPROM and two supply voltage and CPU
temperature controlling devices in particular. Other devices could be connected to the SMBus via the
CompactPCI signals IPMB SCL (J1 B17) and IPMB SDA (J1 C17) or pins 29/30 of the expansion
connectors J_EXPT/J_EXPB.
Address
0x58
0x98
0xA0
0xA4
0xAE
0xD2
© EKF
Function Vendor ID
Number
2 0x8086
3 0x8086
5 0x8086
6 0x8086
0 0x197B
0 0x8086
Hardware Monitor/CPU Temperature Sensor (LM87)
Processor On-Die Temerature Sensor (ADT7421)
SPD of Onboard Memory
General Purpose EEPROM
Main Clock Generation (CK-505)
-54-
TM
2 Duo 3U CompactPCI
Device ID
0x2928 SATA: Non-AHCI/RAID
0x2929 SATA: AHCI Mode
0x282A SATA: RAID 0/1/5/10 Mode
0x2930
0x292D SATA Controller #2
0x2932 Thermal Controller
0x2363 PCIe-SATA-Bridge (JMB362)
0x10D3 Ethernet Controller NC2
Description
SPD of SODIMM
®
CPU Board
Description
1)
1)
1)
SMB Controller
ekf.com
