User Guide CCM-BOOGIE • High Performance Core

Technical Reference

Local PCI Devices

The following table shows the on-board PCI devices and their location within the PCI configuration
space. These devices consist of the Ethernet controllers and several devices within the Intel 4 series
express chip set.
Bus Device
Number Number
0 0
0 2
0 2
0 3
0 3
0 3
0 3
0 25
0 26
0 26
0 26
0 26
0 27
0 28
0 28
0 28
0 28
0 28
0 28
0 29
0 29
0 29
0 29
0 29
0 30
0 31
© EKF
Function Vendor ID
Number
0 0x8086
0 0x8086
1 0x8086
0 0x8086
1 0x8086
2 0x8086
3 0x8086
0 0x8086
0 0x8086
1 0x8086
2 0x8086
7 0x8086
0 0x8086
0 0x8086
1 0x8086
2 0x8086
3 0x8086
4 0x8086
5 0x8086
0 0x8086
1 0x8086
2 0x8086
3 0x8086
7 0x8086
0 0x8086
0 0x8086
-53-
TM
2 Duo 3U CompactPCI
Device ID
0x2A40
0x2A42 Internal Graphics Device
0x2A43 PCI Configuration Regs.
0x2A44 Management Engine 1
0x2A45 Management Engine 2
0x2A46
0x2A47 AMT SOL Redirection
0x10F5 ICH9 Gigabit LAN NC1
0x2937 USB UHCI Controller #4
0x2938 USB UHCI Controller #5
0x2939 USB UHCI Controller #6
0x293C USB 2.0 EHCI Controller #2
0x293E Intel High Definition Audio
0x2940 PCI Express Port 1
0x2942 PCI Express Port 2
0x2944 PCI Express Port 3
0x2946 PCI Express Port 4
0x2948 PCI Express Port 5
0x294A PCI Express Port 6
0x2934 USB UHCI Controller #1
0x2935 USB UHCI Controller #2
0x2936 USB UHCI Controller #3
0x2939 USB UHCI Controller #6
0x293A USB 2.0 EHCI Controller #1
0x2448 DMI-to-PCI Bridge
0x2917
®
CPU Board
Description
Host Bridge
AMT IDER
LPC Bridge
