8.3 LTE LED
Figure 9‐3 LTE LED Symbol
Table 9‐2 LTE LED Definition
LED COLOR
LTE Blue
If the LTE LED is off or blinking continuously, please check:
Step 1PoE cable MUST be connected between QCI4NU and SQO14 device.
Step 2 Re‐power on the QCI4NU device.
Step 3Wait until the LED indicator steadies.
Step 4 If the problem still persists, device hardware component may be defective, please contact
our technical support.
8.4 Wi­Fi LED
Figure 9‐4 WIFI LED Symbol
Table 9‐3 WLAN LED Definition
LED COLOR
WIFI Blue
If the WIFI LED is off, please check:
WIFI: Enable wireless function and all configuration parameters MUST be correct. See the WIFI
configuration for more information.
Figure 8‐3
STATUS DESCRIPTION
Steady On In LTE network
Blinking LTE scan, connect, complete LTE connectivity
OFF No access in LTE network
Figure 8‐4
STATUS DESCRIPTION
OFF
WLAN function disable
Blinking
Data transmission through WLAN
Steady On
WLAN function enable
