- Page 1 BHS-RTA S ADSL Home Station User´s Manual (Ed.1.0) OBJETIVOS Y SERVICIOS DE VALOR AÑADIDO S.L. Made by: Name Arancha Gómez /Maribel Ferrer Charge Product Manager / SW Manager Date 18/07/2014...
- Page 2 BHS-RTA S User´s Manual Page 2 of 52 REVISION LIST EDITION CHANGES Ed. 1.0 18/07/2014: Initial Edition BHS-RTA S User´s Manual.
-
Page 3: Table Of Contents
BHS-RTA S User´s Manual Page 3 of 52 CONTENT .......................... 5 NTRODUCTION 1.1.- ........................6 ACKING 1.2.- ......................6 AFETY RECAUTIONS 1.3.- ......................6 S AND NTERFACES 1.4.- ....................... 8 YSTEM EQUIREMENTS 1.5.- ..........................8 EATURES ......................9 ARDWARE NSTALLATION WIZARD .......................... - Page 4 BHS-RTA S User´s Manual Page 4 of 52 4.6.9 Other configuration ....................... 40 4.6.10 IPv6 ..........................40 4.7.- ........................44 IAGNOSTICS 4.7.1 Ping ..........................44 4.7.2 Packet Dump ........................ 45 4.7.3 ATM Loopback ......................45 4.7.4 ADSL Tone ........................45 4.7.5...
-
Page 5: Introduction
BHS-RTA S User´s Manual Page 5 of 52 1.- Introduction The device supports multiple line modes. With four 10/100 base-T Ethernet interfaces at the user end, the device provides high-speed ADSL broadband connection to the Internet or Intranet for high-end users like net bars and office users. -
Page 6: Packing List
BHS-RTA S User´s Manual Page 6 of 52 1.1.- Packing List 1 x ADSL Home Station (BHS-RTA S) 1 x PSU 12V-1A 1 x RJ11 telephone cable 1 x RJ45 Ethernet cable 1 x Quick Installation Guide 1.2.-... -
Page 7: Rear Panel
BHS-RTA S User´s Manual Page 7 of 52 Color Status Description Solid Problems on WPS registration seconds) Blinking Green Negotiation Solid Green Red/Green Quick Blinking Green Tx/Rx traffic on line Solid Red Authentication failed Traffic through broadband interface Router powered off... -
Page 8: System Requirements
BHS-RTA S User´s Manual Page 8 of 52 1.4.- System Requirements A 10 baseT/100BaseT Ethernet card is installed on your PC. A hub or switch (attached to several PCs through one of Ethernet interfaces on the device) ... -
Page 9: Hardware Installation
BHS-RTA S User´s Manual Page 9 of 52 2.- Hardware Installation Step 1 Connect the ADSL port of the device and the Modem port of the splitter with a telephone cable (if Splitter is available). Step 2 Connect the phone to the Phone port of the splitter through a telephone cable. Connect the incoming line to the Line port of the splitter. -
Page 10: Wizard
BHS-RTA S User´s Manual Page 10 of 52 3.- REDUCED WEB - WIZARD The following is the detailed description of accesing the device for the first time. Step 1 Open the WEB Explorer (IE, Chrome, Firefox,Safari) browser and enter http://192.168.1.1 Step 2 The Welcome page is shown in the following figure. - Page 11 BHS-RTA S User´s Manual Page 11 of 52 Step 4 Here you can select: “Siguiente” to save selected changes, or “Cancelar” to go back to the Welcome page without saving changes, or “Configuración Avanzada” to login into the Advanced WEB UI of the Router with the user admin and password 1234, or “...
- Page 12 BHS-RTA S User´s Manual Page 12 of 52 Step 6 Here you can select: “ Siguiente” to save selected changes or “Cancelar” to go back to the Conectividad page without saving changes, or “Configuración Avanzada” to login into the Advanced WEB UI of the Router with the user admin and password 1234 Once you have finished, push “Siguiente”...
- Page 13 BHS-RTA S User´s Manual Page 13 of 52 Here you can select “ Siguiente” to exit the Wizard and finish your Router´s settings, or “Cancelar” to go back to the Wireless page without saving changes, or “Configuración Avanzada” to login into the Advanced WEB UI of the Router with the user admin and...
-
Page 14: Advanced Web
BHS-RTA S User´s Manual Page 14 of 52 4.- ADVANCED WEB Click in Configuración Avanzada and you will obtain a login box. Credentials are admin as user and 1234 as password. If you log in successfully you will find the following page. -
Page 15: Lan
BHS-RTA S User´s Manual Page 15 of 52 4.2.- You can configure the LAN IP address according to the actual application. The preset IP address is 192.168.1.1. You can use the default settings and DHCP service to manage the IP settings for the private network. -
Page 16: Advanced Configuration
BHS-RTA S User´s Manual Page 16 of 52 The following table describes the parameters in this page. Description Field Deshabilitar interfaz Select this to turn Wi-Fi on or off. WLAN (Disable Wireless) Select the operational Band Mode: B, G, N, B+G, G+N,... -
Page 17: Security
BHS-RTA S User´s Manual Page 17 of 52 4.3.3 Security Select WLAN Seguridad. The page shown in the following figure appears. Wireless security is vital to your network to protect the wireless communication among wireless stations, access points and wired network. - Page 18 BHS-RTA S User´s Manual Page 18 of 52 The following table describes the parameters of this page. For WEP: Field Description Longitud de la clave Choose the WEP key length. You can Choose 64- (WEP Key Length) bit or 128-bit.
-
Page 19: Access Control
BHS-RTA S User´s Manual Page 19 of 52 Description Field address, and password of the Radius server. You need to enter the username and password provided by the Radius server when the wireless client connects the modem. If the encrypton is set to WEP, the modem uses 802.1 X authentication, which is Radius authentication. -
Page 20: Mbssid
BHS-RTA S User´s Manual Page 20 of 52 Field Description Choose to disable WPS function. By default WPS Deshabilitar WPS (Disable WPS) function is enabled, but can be only launched first time from SW page. When Configured state is selected, wireless parameters (for example, the encryption password) are provided by the CPE in WPS negotiation. - Page 21 BHS-RTA S User´s Manual Page 21 of 52 In this page you can also configure a 2 SSID to be used as tunnel GRE with remote peer. Figure showing how change security for SSID in the picture above (Movistar-Wi-fi) Access to several SSID configuration through Varios AP button.
- Page 22 BHS-RTA S User´s Manual Page 22 of 52...
-
Page 23: Wlan Status
BHS-RTA S User´s Manual Page 23 of 52 4.3.7 WLAN STATUS Click WLAN Estado, you will find the page below. 4.4.- In this menu, user can manage all related to internet connection. 4.4.1 DSL WAN To configure internet click on WAN DSL WAN, page shown is the one below. - Page 24 BHS-RTA S User´s Manual Page 24 of 52 Description Field VPI: The virtual path between two points in an ATM network, and its valid value is from 0 to 255. PVC Settings VCI: The virtual channel between two points in an ATM network, ranging from 32 to 65535 (0 to 31 is reserved for local management of ATM traffic).
-
Page 25: Atm Configuration
BHS-RTA S User´s Manual Page 25 of 52 4.4.2 ATM CONFIGURATION From this page is possible to configure ATM parameters for each PVC. 4.4.3 ADSL CONFIGURATION This page allows configure ADSL modulation parameters. -
Page 26: Configuration
BHS-RTA S User´s Manual Page 26 of 52 4.4.4 3G configuration If you want to access the Internet through 3G connection, a 3G USB data card is required. Connect the 3G data card to the USB interface of the Router and go to this page. 3G backup is enable by default, which means that if a 3G dongle is plugged and there is a fail in DSL line, 3G will be up and Internet will be served through 3G dongle. -
Page 27: Pin Configuration
BHS-RTA S User´s Manual Page 27 of 52 4.4.5 PIN CONFIGURATION Click Pin Configuration to enable the 3G PIN code as shown in the following figure. Label “Estado” will inform you about dongle status, if PIN is needed or not, or if modem has been detected. -
Page 28: Vpn: Pptp/L2Tp
BHS-RTA S User´s Manual Page 28 of 52 4.4.8 VPN: PPTP/L2TP Use this section for configuring the settings of VPN(PPTP or L2TP) 4.5.- SERVICES 4.5.1 DHCP By default, Enable DHCP Server is selected for the Ethernet LAN interface of the device. DHCP service supplys IP settings to workstations configured to automatically obtain IP settings that are connected to the device through the Ethernet port. -
Page 29: Dns
BHS-RTA S User´s Manual Page 29 of 52 4.5.2 By clicking on DNS Servidor DNS we can configure manually or automatically DNS for ipv4 and ipv6. By default DNS are set automatically. To configurate Dynamic DNS, click on DNS DNS Dinámico The device supports dynamic domain name service (DDNS). -
Page 30: Firewall
BHS-RTA S User´s Manual Page 30 of 52 4.5.3 Firewall Block IP or port Click on Servicios FirewallBloquear IP/Puerto to access this page. To enable a rule is necessary to fill if the action is for outgoing/incoming traffic, choose Deny or Accept and click Apply. - Page 31 BHS-RTA S User´s Manual Page 31 of 52 Bloquear MAC Click on Servicios Firewall Bloquear MAC to access to this page. In this page you can block the access depending on MAC address. In this configuration page it’s possible also to choose if the restriction is for outgoing or incoming traffic and if the rule denies or accepts the traffic.
- Page 32 BHS-RTA S User´s Manual Page 32 of 52 Bloquear URL Click on Servicios Firewall Bloquear URL to access this page. This page allows user to block domain name FQDN and filter by words. Page is divided in two sections, first one to filter by domain FQDN and second one to filter by words.
-
Page 33: Upnp
BHS-RTA S User´s Manual Page 33 of 52 Click on Servicios Firewall DMZ to access this page. Since some applications are not compatible with NAT, the device supports the use of a DMZ IP address for a single host on the LAN. This IP address is not protected by NAT and it is visible to agents on the Internet with the correct type of software. -
Page 34: Rip
BHS-RTA S User´s Manual Page 34 of 52 4.5.5 Click on Servicios RIP to access to this page. This page is used to select the interfaces on your device that use RIP and the version of the protocol used. -
Page 35: Bridging
BHS-RTA S User´s Manual Page 35 of 52 4.6.2 Bridging This page is used to configure bridge parameters. In this page, you can change the settings or view some information of the bridge and its attached ports. Click on Avanzado Bridging to access to this page. -
Page 36: Snmp
BHS-RTA S User´s Manual Page 36 of 52 Click on button “Mostrar rutas” to see info below. 4.6.4 SNMP Click on Avanzado SNMP to access this page. In this page, you can set SNMP parameters... -
Page 37: Ip Qos
BHS-RTA S User´s Manual Page 37 of 52 4.6.5 IP QoS Click on Avanzado IP QoS, to get IP QoS configuration menu. There are two pages to configure it: Cola QoS and Clasificación. Cola QoS In this page it’s possible to see QoS queue list. -
Page 38: Remote Access
BHS-RTA S User´s Manual Page 38 of 52 4.6.6 Remote access Click on Avanzado Acceso Remoto to see this page. At access remote page you can choose whether services are accessible or not via LAN/WAN. When one service is enabled for WAN, user can enter an IP range in the table below:... -
Page 39: Printer
BHS-RTA S User´s Manual Page 39 of 52 4.6.7 Printer In this page it’s possible to see what is the url assigned to the printer. Click on Avanzado Servidor de impresora, to access here. 4.6.8 SAMBA To enter this page, click on Avanzado Servidor de Archivos. -
Page 40: Other Configuration
BHS-RTA S User´s Manual Page 40 of 52 4.6.9 Other configuration IP passthrough is an option for your DSL modem to turn into a "Bridge" or be just a simple modem - whatever comes down the pipe from the internet goes right on through to your network without any filtering or routing 4.6.10 IPv6... - Page 41 BHS-RTA S User´s Manual Page 41 of 52 RADVD In this page you can configure router advertisement daemon, It sends Router Advertisement messages, to a local Ethernet LAN periodically and when requested by a node sending a Router Solicitation message. These messages are required for IPv6 stateless autoconfiguration.
- Page 42 BHS-RTA S User´s Manual Page 42 of 52 Proxy MDL MLD Snooping...
-
Page 43: Ipv6 Routing
BHS-RTA S User´s Manual Page 43 of 52 IPv6 Routing This page can be used to configure static routing for ipv6. From this page, user can add or remove new routes. -
Page 44: Diagnostics
BHS-RTA S User´s Manual Page 44 of 52 Block IP/Port In this page, it’s possible to block an specific IP and ports. User must choose between outgoing/incoming traffic, protocol and accept or deny that traffic. 4.7.- Diagnostics From these pages, user can use many Diagnostic tools to know which the router state is. -
Page 45: Packet Dump
BHS-RTA S User´s Manual Page 45 of 52 4.7.2 Packet Dump Packet Dump is a useful tool to capture traffic. Open wireshark and follow instructions listed in the page. You may enter interface you want to capture, for instance –s 1500 –i wlan0. -
Page 46: Adsl Conectivity
BHS-RTA S User´s Manual Page 46 of 52 4.7.5 ADSL Conectivity Click on Diagnóstico Conectividad ADSL to access to this page. Choose ppp interface and click on “Comenzar” button. This page will show you a list of individuals tests and if... -
Page 47: Administrator
BHS-RTA S User´s Manual Page 47 of 52 4.8.- ADMINISTRATOR 4.8.1 Save and Reboot In this page you can reboot the device. CPE will save changes in your configuration and they will be stored and ready even after the reboot. -
Page 48: Close Session
BHS-RTA S User´s Manual Page 48 of 52 4.8.3 Close Session This page closes current session. User will be log out and router will ask again for credentials. This way user profile can be changed. 4.8.4 System log This page displays event log data in the chronological manner. You can read the event log from the local host or send it to a system log server. -
Page 49: Password
BHS-RTA S User´s Manual Page 49 of 52 4.8.5 Password In the page Administrador Contraseña, user can change the current password for accessing management web. This change can be performed for different profiles. if user does not fill those fields requiring new password, no authentication will be asked. -
Page 50: Time Zone
BHS-RTA S User´s Manual Page 50 of 52 4.8.8 Time Zone By default, NTP Server synchronization is disabled. We can enable it in Administrador Zona horaria, checking “Habilitar sincronización de hora vía NTP”. Then we apply changes. In the Time and Date page, you can configure, update, and maintain the correct time on the internal system clock. - Page 51 BHS-RTA S User´s Manual Page 51 of 52 ACS parameters URL: Enter the website of ACS which is provided by your ISP. User Name/Password: Enter the User Name and password the device should use when connecting to the ACS.
-
Page 52: E D I T I O N E D
BHS-RTA S User´s Manual Page 52 of 52 4.9.- Statistics Go to Statistics menu to see ADSL and Interface statistic. In this menu it’s possible to check network statistics and data transfer. This information helps technicians to identify if the device is functioning properly.
